SOUND‐INSULATED SMOKE EXTRACTION FAN
Iso-VS
EN
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Iso-VS and is the answer not in the manual?

Questions and answers

Summary of Contents for BLAUBERG Iso-VS

  • Page 1 SOUND‐INSULATED SMOKE EXTRACTION FAN Iso-VS USER’S MANUAL...
  • Page 2: Table Of Contents

    Warranty card ....................................19 This user’s manual is a main operating document intended for technical, maintenance, and operating staff . The manual contains information about purpose, technical details, operating principle, design, and installation of the Iso-VS unit and all its modifi cations.
  • Page 3 Iso-VS www.blaubergventilatoren.de All operations described in this manual must be performed by qualifi ed personnel only, properly trained and qualifi ed to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself.
  • Page 4: Purpose

    1 pc. User’s manual 1 pc. Packing box 1 pc. DESIGNATION KEY Iso-VS – 63 – 4 D/ 4 – U1 Climatic category U1 – temperate climate HL1 – cold climate T1 – tropical climate M1 – maritime moderately cold climate Motor power [kW] x –...
  • Page 5: Technical Data

    Iso-VS www.blaubergventilatoren.de TECHNICAL DATA The fan is designed for extract ventilation of premises with air temperatures ranging from -25 °C up to +400 °C. The fan is rated as a class I electric appliance. The fan’s design is constantly being improved, thus some models may slightly diff er from those described in this manual.
  • Page 6 Iso-VS www.blaubergventilatoren.de Dimensions [mm] Model Weight [kg] Iso-VS 28 2D Iso-VS 28 2E Iso-VS 31 2D 50,6 Iso-VS 31 2E 50,6 Iso-VS 31 4D 46,5 Iso-VS 31 4E 46,5 Iso-VS 35 4D 61,6 Iso-VS 35 4E 61,6 Iso-VS 40 4D...
  • Page 7 Iso-VS www.blaubergventilatoren.de FANS OPTIONS EVA ISO-VS Dimensions [mm] Weight Model [kg] EVA Iso-VS 315 3.79 EVA Iso-VS 355 4.25 EVA Iso-VS 400 4.76 EVA Iso-VS 450 5.34 EVA Iso-VS 500 6.12 EVA Iso-VS 560 6.83 EVA Iso-VS 630 7.66 EVA Iso-VS 710...
  • Page 8 Iso-VS www.blaubergventilatoren.de RSD ISO-VS Dimensions [mm] Weight Model [kg] RSD Iso-VS 315 2.42 RSD Iso-VS 355 3.25 RSD Iso-VS 400 3.91 RSD Iso-VS 450 4.21 RSD Iso-VS 500 6.57 RSD Iso-VS 560 7.71 RSD Iso-VS 630 1003 1022 9.27 RSD Iso-VS 710...
  • Page 9: Design And Operating Principle

    The aluminum zinc casing with high corrosion resistance and heat-insulating material makes the fan suitable for outdoor mounting. The Iso-VS fan is equipped with an asynchronous motor with an external rotor and a centrifugal impeller with backward curved blades. The fan is specially designed to enable the position of the side panels to be changed to supply air in 90° directions.
  • Page 10: Mounting And Set-Up

    Iso-VS www.blaubergventilatoren.de MOUNTING AND SET-UP BEFORE MOUNTING MAKE SURE THE CASING DOES NOT CONTAIN ANY FOREIGN OBJECTS (E.G. FOIL, PAPER). WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT MAINTENANCE AND REPAIR. Before installing the fan, make sure that there is no visible damage to the impeller and check the integrity of the insulation of the power supply wires.
  • Page 11 Installing the drain fi tting mounting brackets horizontal plane. fan can be equipped with a protective cover – RSD Iso-VS The MH Iso-VS brackets and the RSD Iso-VS protective cover are not included in the delivery set and must be ordered separately.
  • Page 12: Connection To Power Mains

    Iso-VS 28 2D 1~230 V 3~400 V Iso-VS 31 2D, Iso-VS 31 4D, Iso-VS 35 4D, Iso-VS 40 4D, Iso-VS 45 4D, Iso-VS 50 4D, Iso-VS 31 2E, Iso-VS 31 4E, Iso-VS 35 4E, Iso-VS 56 4D, Iso-VS 63 4D, Iso-VS 71 4D,...
  • Page 13: Commissioning

    Iso-VS www.blaubergventilatoren.de COMMISSIONING THE ORGANISATION RESPONSIBLE FOR THE COMMISSIONING SHALL BE RESPONSIBLE FOR PROPER MOTOR PHASING AND STARTING PATTERN SELECTION. WHEN STARTING, THE FAN'S CURRENT VALUES MAY INCREASE SEVERAL TIMES COMPARED TO THE RATED ONES • After fan starting make sure that the electric motor rotates properly without undue vibration and abnormal noise.
  • Page 14: Troubleshooting

    Iso-VS www.blaubergventilatoren.de TROUBLESHOOTING TROUBLE POSSIBLE REASONS TROUBLESHOOTING Make sure the power supply line is connected correctly, otherwise Fan unit does not start. No power supply. troubleshoot the connection error. The ventilation system is Low air fl ow. Check the air ducts for clogging. Clean the air ducts if necessary.
  • Page 15: Manufacturer's Warranty

    Iso-VS www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 16 Iso-VS www.blaubergventilatoren.de...
  • Page 17 Iso-VS www.blaubergventilatoren.de...
  • Page 18 Iso-VS www.blaubergventilatoren.de...
  • Page 19: Certificate Of Acceptance

    Iso-VS www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Sound-insulated smoke extraction fan Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 20 www.blaubergventilatoren.de B295EN-01...
