CONTENTS Delivery set ................................................8 Brief description ..............................................8 Operation guidelines ............................................8 Installation and set-up............................................. 9 Electronics operation algorithm ......................................9 Fan setup ................................................. 10 Technical maintenance ........................................... 11 Storage and transportation regulations ....................................11 Manufacturer’s warranty ..........................................12 This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
Page 3
FOLLOW THE USER’S MANUAL REQUIREMENTS TO ENSURE DURABLE AND TROUBLE-FREE OPERATION OF THE UNIT This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for their safety.
Page 4
Connection to the mains must be made through a disconnecting device, which is integrated into the fixed wiring system in accordance with the wiring rules for design of electrical units, and has a contact separation in all poles that allows for full disconnection under overvoltage category III conditions.
Page 5
All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself.
Page 6
Check the unit for any visible damage of the impeller, the casing, and the grille before starting installation. The casing internals must be free of any foreign objects that can damage the impeller blades. While mounting the unit, avoid compression of the casing! Deformation of the casing may result in motor jam and excessive noise.
Page 7
Do not sit on the unit and do not put objects on it. The information in this user’s manual was correct at the time of the document’s preparation. The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time in order to incorporate the latest technological developments.
DELIVERY SET — 1 pc. Screws with dowels — 4 pcs. Plastic screwdriver (for all models with a timer) — 1 pc. User’s manual — 1 pc. Packing box — 1 pc. BRIEF DESCRIPTION The unit described herein is an axial fan for exhaust ventilation of small to medium-sized premises heated during winter. It is designed for wall or ceiling mounting (Fig.
INSTALLATION AND SET-UP The fan is designed for wall or ceiling mounting with direct air exhaust to the ventilation shaft or into the round air duct of matching diameter (Fig. 2). Fan installation sequence: step 1. Cut off power supply and make sure electricity has been turned off (Fig. 5). step 2.
FAN SETUP — to adjust the fan turn-off delay time, turn the control knob T clockwise to increase and counter-clockwise to decrease the turn-off delay time respectively, adjustable from 2 up to 30 minutes. 2 min 30 min DO NOT USE A METAL SCREWDRIVER, KNIFE, ETC. FOR ADJUSTMENT OPERATIONS NOT TO DAMAGE THE CIRCUIT BOARD...
TECHNICAL MAINTENANCE The fan maintenance periodicity is at least once per 6 months. Maintenance steps: • Disconnect the fan from power supply and make sure electricity has been turned off (Fig. 15). • Remove the front and the decorative panels, wipe the fan with a dry cloth or a brush (Fig. 16). •...
Our ventilation products also come with a two year limited warranty given by Blauberg Australasia Pty Ltd, with an office at Unit 5, 45A Eastern Creek Drive, Eastern Creek, New South Wales 2766, as set out in the instruction manual in the box.
Page 13
USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON PRESENTATION OF THE UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL WITH THE PURCHASE DATE STAMP 4.5x4 Dimensions [mm] Weight Model [kg] BLABAERO 100 (T) 92.5 29.5 0.56 BLABAERO 125 0.73 BLABAERO 150 (T)
Page 17
Fan does not run BLABAERO Contact of the S switch is CLOSED Fan runs Contact of the S switch is OPENED Fan does not run BLABAERO T Contact of the S switch is CLOSED Fan runs Contact of the S switch is OPENED Activation of turn-off...
Page 19
Quality Inspector’s Stamp Sold by (name and stamp of the seller) Manufacture Date Purchase Date...
