4 - Customising the UPS operating mode
UPS STATUS
UPS Info
Output
Input
Batteries
History Data
Misc.
UPS STATUS
UPS Info
Mod Megaline xxxx
POut Max xxxx
SWVer. xxxx
S/N xxxxxxxxx
Installed Modules x
Faulty Modules
Output
Power xxxxx
Appar.Pow. xxxx
V RMS xxxx
I RMS xxxx
Peak current
Frequency
I Crest factor
Power fact.
MAIN MENU
UPS Status
UPS Config.
Events
Programming
Tools
UPS Setup
Output
Input
Bypass
Neutral Sensor
Batteries
Clock setup
Operator Panel
Mod
➧
POut max
SWVer.
S/N
Installed Modules
x
Faulty Modules
Power
Appar. Pow.
➧
V RMS
xx
I RMS
xx
xx
Peak current
xx
Frequency
I Crest factor
Power fact.
Events
log View
Schedule Planning
log Reset
Restart
Shutdown Planning
Indicates the name of the UPS
Indicates the potential maximum active power (W)
Software version
Serial number
Number of power modules fitted
Number of power modules that have failed
Indicates the active power supplied (W)
Indicates the apparent power supplied (VA)
Indicates the effective voltage (V RMS) supplied at the UPS
output
Indicates the effective current (A RMS) supplied at the UPS
output
Indicates the peak current supplied at the UPS output (A)
Indicates the frequency of the UPS output voltage (Hz)
Indicates the crest factor, calculated as the ratio between
the peak value and the effective value of the current
absorbed by the load
Indicates the power factor for the load connected to the UPS
39
Scheduling
Signalling Test
LCD Display Test
Battery Test
Battery Calibration
Tools
