4. Customising the UPS operating mode
The functions of the buttons
The buttons on the front panel of the UPS are used to access its various menus
BUTTON
- Exit a function without modifying it
- Go up a level to an upper level menu
ESC
- Exit the main menu and return to status display
- Silence the buzzer
- Select previous function
- Increase a value within the function
- Select a new item within the function (e.g. go from DISABLED to ENABLED)
- Select next function
- Reduce a value within the function
- Select a new item within the function (e.g. go from ENABLED to DISABLED)
- Confirm a value
- Access an item in the menu
- Go down a level to a lower level menu
!
ATTENTION: Some menus contain more than four lines: use the
through items in the menu that are not displayed.
The "Service Mode" Function
All the settings and programming described below can be done even when the UPS is switched off. Press the
button to enter UPS "SERVICE" mode in order to access the Display menu. Press the
Alternatively, the UPS will automatically exit the function and switch off if it does not receive manual or serial commands
within 1 min.
Accessing menus
When the UPS switch on procedure has been completed, the display will read
(example)
UPS on Mains
IN 212V
OUT 230V/812W ( 31%)
Batt
Press the
32,2'
4 - Customising the UPS operating mode
DESCRIPTION
button to access the main menu
38
buttons to scroll
button to exit this mode.
