Tx-1, Tx-3 and Tx-10 transmitters

1
2
4
5
10 11
8
13
14
15
16
9
3
7 6
12 17
18
19
20
8

Transmitter features

1. Keypad.
2. LCD.
3.

Transmitter keypad

4. Power key: Switches the unit on
and off. Opens the transmitter menu.
5.
6. Up and down arrows: Adjusts the
output level signal. Scrolls through the
menu options.
7.
display between volts and current
or resistance and power
(Note:
displayed measurements are based
on the currently selected mode or
the attached accessory, if applicable)

Transmitter screen icons

8. Battery icon: Indicates the battery level.
9. Selected operation mode.
10. Standby icon: Appears when the
11. Output level: Displays transmitter
output level.
12. Clamp icon: Indicates when a clamp
is connected.
13. External 12V DC icon: Appears when
the transmitter is powered from an
external 12V DC source.
14. Induction indicator: Appears when the
15. A-Frame: Indicates when the
(Tx-3 and Tx-10 models only)
16.
(Tx-10 model only)
17. Voltage warning indicator: Indicates
that the transmitter is outputting
potentially hazardous voltage levels.
18. Volume icon: Displays the volume level.
19. Pairing icon (Tx-3B and Tx-10B only).
Bluetooth
20. ® icon (Tx-3B and Tx-10B
only.
