Pulsar Esprit
3–13.5 kVA
High Availability UPS for Internet Servers
MGE UPS SYSTEMS all new Pulsar Esprit has been specifically
designed to meet the needs of Internet Service Providers & Application
Service Providers. Esprit provides total power availability with redundant
UPSs for the price of a regular, single UPS. This redundant combination,
called Power Cluster, has been pioneered exclusively by MGE.
Pulsar Esprit has been designed with the Internet in mind:
For the first time, it is possible to remotely monitor an UPS using
XML tags to perform automatic actions. This breakthrough technology
is the result of MGE's heavy investment in research and development.
They provide ISPs with the best combination of power availability
and cost. With the revolutionary Esprit Power Cluster, MGE brings
affordable, total power availability to smaller ISPs and mid-size
businesses with 3 to 15 servers.
Pulsar Esprit World First. . .
First high availability UPS with maximum reliability
at an affordable cost (Power Cluster)
First UPS with infinitely expandable batteries
First UPS to provide "redundant hot swap" battery capability
First server-grade UPS with built-in USB communications
First UPS in its class with HID protocol for seamless
integration with Windows 2000
First UPS managed with XML tags
Advanced Features
High availability power
+ maximum reliability =
MGE Power Cluster
Web-based management
using XML
Standard USB
communications
Seamless integration
with Microsoft
Windows 2000
Redundant battery
back-up potential
Redundant
battery chargers
(with additional batteries)
Plug-in convenience
up to 8.5 kVA
Can be installed by
non-technical personnel
Capable of long
duration backup

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pulsar Esprit 313.5 kVA and is the answer not in the manual?

Questions and answers

Summary of Contents for MGE UPS Systems Pulsar Esprit 313.5 kVA

  • Page 1 Pulsar Esprit 3–13.5 kVA High Availability UPS for Internet Servers MGE UPS SYSTEMS all new Pulsar Esprit has been specifically designed to meet the needs of Internet Service Providers & Application Service Providers. Esprit provides total power availability with redundant UPSs for the price of a regular, single UPS.
  • Page 2 Power Supplies Example of 5 PC servers with 3 redundant power supplies: Select a 4.5 kVA Esprit Power Cluster Connect the first power supply Connect the second power supply Connect the third power supply Connect each Esprit to a separate wall outlet.
  • Page 3: Battery Module

    Easy Connections and Installation Electronic Module (Esprit 3.1) Versatile output receptacles Various combinations of receptacles make it easy to connect any type of server to your Esprit Infinite battery runtime You can “parallel daisy chain” as many battery modules as needed. Battery Module Plug-In convenience up to 9 kVA Simple installation: simply plug...
  • Page 4: Snmp Management

    Web-based Management Using XML MGE UPS SYSTEMS is currently chairing the W3C UPS industry workgroup, which will define an industry standard for power management over the Web. XML will quickly replace HTML as the protocol of choice for web-based management. HTML can only display information in a browser, it cannot easily send the data to another piece of software to perform an automatic action such as triggering a shut down command of the system or paging an administrator.
  • Page 5 Select the Esprit you need for your Web Servers Model Single UPS 3-server protection Esprit 3.1 3.0 kVA 5U (in rack) 5-server protection Esprit 4.5 4.5 kVA 5U (in rack) 6-server protection Esprit 6 6 kVA 10U (in rack) 9-server protection Esprit 9 8.5 kVA 10U (in rack)
  • Page 6: Specifications

    (905) 672-0990 (877) 672-0990 (714) 557-1636 fax (905) 672-7667 (714) 557-9788 ©MGE UPS SYSTEMS, Inc. All specifications subject to change without notice. The MGE UPS SYSTEMS logo is a trademark of MGE UPS SYSTEMS. Esprit 4.5 Weight (lbs.) 4 PC...
