EVAL-AD7177-2SDZ User Guide

SOCKETS AND CONNECTORS

Table 2. Connector Details
Connector Function
J1 Connector to the
J2 External MCLK input
J3 External bench top voltage supply for
the EVAL-AD7177-2SDZ
J5 External ac-to-dc adapter input for the
EVAL-AD7177-2SDZ, 7 V to 9 V
J6 Analog input terminal block; wired
connection to external source or sensor
J9 External bench top voltage supply
option for AVDD1/AVDD2, IOVDD, and
AVSS inputs on the
J10 Optional header
J13 Optional header
A0 to A4 Analog inputs to ADC
A7 PMOD-compatible header
Order codes starting with FEC are for Farnell.
1
Connector Type
EVAL-SDP-CB1Z 120-way connector,
0.6 mm pitch
Straight PCB mount
SMB/SMA jack
Power socket block,
3-pin, 3.81 mm pitch
DC power
connectors, 2 mm
SMT power jack
Power socket block,
8-pin, 3.81 mm pitch
Screw terminal block,
3.81 mm pitch
AD7177-2
7-way, 2.54 mm pin
header
7-way, 2.54 mm
socket
Straight PCB mount
SMB/SMA jack
6-Pin SIL header
(0.1" pitch)
Manufacturer
Hirose
Tyco
Phoenix
Contact
Kycon
Phoenix
Contact
Phoenix
Contact
Samtec
Samtec
Tyco
Harwin
Rev. 0 | Page 5 of 14
UG-849
Manufacturer
Number Order Code
FX8-120S-SV(21) FEC1324660
1-1337482-0 Not applicable
MC 1,5/ 3-G-3,81 FEC3704737
KLDX-SMT2- MOUSER 806-
0202-A KLDX-SMT20202A
MC 1,5/ 8-G-3,81 FEC3704774
MKDS 1/4-3.81 FEC3704592
SSW-107-01-T-S FEC1803478
TLW-107-05-G-S FEC1668499
1-1337482-0 Not applicable
20-9990646 FEC 1022255
1
