5 MELSEC FUNCTIONS

5.10.9 32-bit data logical sum (3 devices)

The specified two BIN 32-bit data are ORed bit by bit.
Function definition

5.10.10 Block data logical sum

n points of 16-bit data, starting at the specified two devices, are ORed bit by bit.
Function definition
5 - 43
BOOL DOR_3_M (BOOL EN, ANY32 S1, ANY32 S2, ANY32 D);
Argument Name
EN
S1
S2
D
Remarks: For bit devices, the bits greater than in the digit specification are
processed as "0 (zero)".
Return Value
BOOL Execution condition
Example of use
(* When execution condition X0 turns ON, the 32-bit data in dwData1 and the *)
(* 32-bit data in X20 to X3F are ORed, and the result is output to Result.
DOR_3_M (X0, dwData1, K8X20, Result);
Corresponding MELSEC command
DOR (32-bit data logical sum)
BKOR_M
BOOL BKOR_M (BOOL EN, ANY16 S1, ANY16 S2, ANY16 n, ANY16 D);
Argument Name
EN
S1
S2
n
D
Return Value
BOOL Execution condition
Example of use
(* When execution condition X0 turns ON, the data of the number of points
(* stored in D0, starting at D10, and the data of the number of points stored in *)
(* D0, starting at D20, are ORed, and the result is stored into D100 and later.
BKOR_M (X0, D10, D20, D0, D100);
Corresponding MELSEC command
BKOR (Block logical sum)
DOR_3_M
IN/OUT
Execution condition (Function is executed only when
IN
the result is TRUE)
IN Data to be ORed (BIN 32-bit data)
IN Data to OR (BIN 32-bit data)
OUT Operation result (BIN 32-bit data)
IN/OUT
Execution condition (Function is executed only when
IN
the result is TRUE)
IN Data to be ORed (BIN 16-bit data)
IN Data to OR (BIN 16-bit data)
IN Number of data to be processed (BIN 16-bit data)
OUT Operation result (BIN 16-bit data)
For the usable data type, refer to "3.2.2
About ANY type".
Description
Description
Description
Description
*)
*)
*)
