Evaluation Kit for CMX7x6x

Signal Lists

4
CONNECTOR PINOUT
Connector Connector
Ref.
Pin No.
J1
SLEEVE
J2
SLEEVE
J3
SLEEVE
J4
SLEEVE
J5
J7
© 2011 CML Microsystems Plc
Signal
Name
IP1
TIP
N/C
RING
GNDA
IP2
TIP
N/C
RING
GNDA
SPKR1_P
TIP
N/C
RING
SPKR1_N
SPKR2
TIP
N/C
RING
GNDA
1 CLK EXT
1 GPIO0/SSIN/F
SI
2
GPIO1/CLKI
3 GPIO2/SSOU
T2
4 GPIO3/TXD
5 GPIO4/RXD
6 GPIO5/IRQN
7 GPIO6/CSN
8 GPIO7/CMD_
DATA
9 GPIO8/REP_
DATA
10 GPIO9/SCLK
Signal
Type
I/P Audio 1 input.
-
PWR Analogue ground.
I/P Audio 2 input.
-
PWR Analogue ground.
O/P Speaker 1 (8ohm) +ve.
-
O/P Speaker 1 (8ohm) -ve.
O/P Speaker 2 (32ohm).
-
PWR Analogue ground.
I/P External input option for CMX7x6x clock (not
fitted).
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
BI CMX7x6x signal, FI dependent.
9
PE0601-xxxx
Description
UM0601/2
