CML Microcircuits PE0601 Series User Manual page 12

Evaluation Kit for CMX7x6x
CONNECTOR PINOUT
Connector Connector
Ref.
Pin No.
J13 7
8
9, 10
J16 3
2
1
J17 1
J18 1
J19 1
2
3
4
5, 6
7
8
9
10
J20 1
J21 1
J22
1
2
3
4
© 2011 CML Microsystems Plc
Signal Signal
Name Type
AUXADC0 I/P
AUXDAC3 O/P
GNDA PWR
+V PWR
0V PWR
-V PWR
I_IN I/P
Q_IN I/P
I_OUTP_I I/P
I_OUTP O/P
I_OUTN_I I/P
I_OUTN O/P
GNDA PWR
Q_OUTP_I I/P
Q_OUTP O/P
Q_OUTN_I I/P
Q_OUTN O/P
I_OUT O/P
Q_OUT O/P
O/P
RF_MOSI
RF_SCLK I/P
GPIO12/MOSI BI
/SDO
GPIO14/MISO BI
/SDI
Auxiliary ADC input.
Auxiliary DAC output.
Analogue ground.
External supply voltage, nominally +5 volt.
External supply ground.
Optional external negative supply voltage,
nominally -5 volt.
I channel instrument input, single ended.
Q channel instrument input, single ended.
I channel output positive, instrumentation input.
I channel output positive.
I channel output negative, instrumentation input.
I channel output negative.
Analogue ground.
Q channel output positive, instrumentation input.
Q channel output positive.
Q channel output negative, instrumentation input.
Q channel output negative.
I channel instrumentation output, single ended.
Q channel instrumentation output, single ended.
RF Serial Data.
RF Serial Clock.
CMX7x6x signal, FI dependent.
CMX7x6x signal, FI dependent.
12
PE0601-xxxx
Description
UM0601/2
