Evaluation Kit for CMX7x6x
2. From the on-board PE0601 serial memory. To use this method the serial memory must first
be programmed with the FI by using the 'Program Serial Memory' tab on the PE0002 GUI
software.
The PE0601 should now be ready for evaluation of the CMX7x6x with the chosen FI.
Please note that to access the CML Technical Portal you need to be authorised by a member of
the CML sales staff. Please contact your local distributor, representative or area sales manager.
3.2

Without PE0002

As an alternative to using the PE0002 controller kit, users may control the CMX7x6x target device
with a user-supplied host controller card. C-BUS connections are made via connector J10.
The power-up, or boot state of the CMX7x6x BOOTEN1 and BOOTEN2 pins may be set using
jumpers JP1 and JP2. Consult the relevant CMX7x6x documentation for valid modes. A jumper
in-circuit corresponds to a '0' state on the boot pins. Alternatively the state of these pins may be
set via the connector, J10, pins 13 and 14. If jumpers JP1 and JP2 are left open circuit and the
BOOTEN pins are not driven from connector J10, then by default, they are pulled high by the
CMX7x6x device.
A FI for the CMX7x6x device must be either included in the customer's host system and loaded
into the CMX7x6x device on power-up or programmed into the on-board serial memory following
the guidelines in the application note: 'Writing a Function Image
from the Application Notes area of the CML website.
© 2011 CML Microsystems Plc
TM
8
PE0601-xxxx
to Serial Memory'; available
UM0601/2
