CML Microcircuits PE0601 Series User Manual page 10

Evaluation Kit for CMX7x6x
CONNECTOR PINOUT
Connector Connector
Ref.
Pin No.
J7 11
12
13
14
15
16
17
18
19, 20
J8 1
2
3
4
5
6
7
8
9
10
J10 1
2
3
4
5
© 2011 CML Microsystems Plc
Signal Signal
Name Type
GPIO10/SYS BI
CLK2
GPIO11/SYS BI
CLK1
GPIO12/MOSI BI
/SDO
GPIO13/SSO BI
UT1/FSO
GPIO14/MISO BI
/SDI
GPIO15/SSO BI
UT0
CLK/CLKO BI
N/C -
GNDD PWR
N/C -
SPKR_2_OP O/P
GNDA PWR
GNDA PWR
SPKR_1_OP_ O/P
N
SPKR_1_OP_ O/P
P
SPKR_3V3 PWR
SPKR_1_VDD PWR
IP2 I/P
IP1 I/P
RESETN I/P
CSN I/P
RFCSN I/P
CDATA I/P
RF_MOSI I/P
CMX7x6x signal, FI dependent.
CMX7x6x signal, FI dependent.
CMX7x6x signal, FI dependent.
CMX7x6x signal, FI dependent.
CMX7x6x signal, FI dependent.
CMX7x6x signal, FI dependent.
CMX7x6x SSP clock signal, FI dependent.
Digital ground.
Speaker 2 (32ohm) output.
Analogue ground.
Analogue ground.
Speaker 1 (8ohm) -ve.
Speaker 1 (8ohm) +ve.
Dedicated 3.3 volt power rail for speaker 1
output.
DC supply for speaker 1.
Audio input.
Audio input.
CMX7x6x Reset control.
Chip Select. Connects to host μC.
RF Serial Chip Select.
Serial data input. Connects to host μC.
RF serial data.
10
PE0601-xxxx
Description
UM0601/2
