CML Microcircuits PE0601 Series User Manual page 17

Evaluation Kit for CMX7x6x
JUMPERS
Link
Positions
Ref.
JP1 1-2
JP2 1-2
JP8 1-2
JP11 1-2
JP13 1-2
JP14 1-2
J6 1-2
3-4
5-6
7-8
9-10
J8 7-8
J14 1-2
3-4
5-6
7-8
9-10
11-12
13-14
15-16
17-18
19-20
J19 1-2
3-4
7-8
9-10
© 2011 CML Microsystems Plc
Default
Position
Open Manual BootEn1 control (short = LO).
Open Manual BootEn2 control (short = LO).
Open Allow CMX7x6x GPIO3/4 to drive LEDs D2/3.
Short Isolates analogue supply rail from CMX7x6x.
Short Isolates digital supply rail from CMX7x6x.
Open Isolates external +1.8 volt supply rail from CMX7x6x.
Short 19.2MHz oscillator clock source.
Open External clock source.
Open Crystal clock source – if components fitted by customer.
Short Ground external clock input.
Open Crystal clock source – if components fitted by customer.
Short Isolates +3.3 volt supply of speaker 1 driver.
Open Isolates GPIO2/SSOUT2 from C-BUS master on J11.
Open Isolates GPIO6 from C-BUS master on J11.
Open Isolates GPIO7 from C-BUS master on J11.
Open Isolates GPIO8 from C-BUS master on J11.
Open Isolates GPIO11 from C-BUS master on J11.
Open Isolates GPIO9 from C-BUS master on J11.
Open Isolates GPIO4 from C-BUS master on J11.
Open Isolates GPIO3 from C-BUS master on J11.
Open Isolates GPIO10 from C-BUS master on J11.
Open Isolates GPIO15/SSOUT0 from C-BUS master on J11.
Open Isolates I channel output +ve from instrumentation
interface.
Open Isolates I channel output -ve from instrumentation
interface.
Open Isolates Q channel output +ve from instrumentation
interface.
Open Isolates Q channel output -ve from instrumentation
interface.
17
Description
PE0601-xxxx
UM0601/2
