CML Microcircuits PE0601 Series User Manual page 14

Evaluation Kit for CMX7x6x
CONNECTOR PINOUT
Connector Connector
Ref.
Pin No.
J22
40
41
42
43
44
45
46, 47, 48
49
50
51
52
53
54
55
56
57
58
59
60
J23 1, 2
3 to 6
J24 1
2
3
4
5, 6
7
8
© 2011 CML Microsystems Plc
Signal Signal
Name Type
GNDA PWR
AUXADC0 I/P
I/P
AUXADC2
GNDA PWR
O/P
AUXDAC3
AUXDAC1 O/P
GNDA PWR
+V PWR
NC -
GNDD PWR
GPIO10/SYS BI
CLK2
GNDD PWR
GPIO4/RXD BI
GPIO0/SSIN/F BI
SI
GNDD PWR
GPIO5/IRQN BI
CLK/CLKO BI
RFCSN O/P
GPIO1/CLKI BI
GNDD PWR
+V PWR
I_INP_I O/P
I_INP I/P
I_INN_I O/P
I_INN I/P
GNDA PWR
Q_INP_I O/P
Q_INP I/P
Analogue ground.
Auxiliary ADC input.
Auxiliary ADC input.
Analogue ground.
Auxiliary DAC output.
Auxiliary DAC output.
Analogue ground.
External supply voltage, nominally +5 volt.
Digital ground.
CMX7x6x signal, FI dependent.
Digital ground.
CMX7x6x signal, FI dependent.
CMX7x6x signal, FI dependent.
Digital ground.
CMX7x6x signal, FI dependent.
CMX7x6x SSP clock signal, FI dependent.
RF Serial Chip Select.
CMX7x6x signal, FI dependent.
Digital ground.
External supply voltage – daisy-chained from
PE0002.
I channel input positive, instrumentation output.
I channel input positive.
I channel input negative, instrumentation output.
I channel input negative.
Analogue ground.
Q channel input positive, instrumentation
output.
Q channel input positive.
14
PE0601-xxxx
Description
UM0601/2
