MHG Heating ProCon HT 150 Installation And Operating Manual page 53

8802 Room model temperature HC3/P
Flow temperature setpoint resulting
8803
8820 State DHW pump (Q3)
DHW temperature actual value top
8830
8831 DHW temperature setpoint current
DHW temperature actual value bottom
8832
8835 DHW circulating temperature
8836 DHW charging temperature
DHW pre controller temperature actual
8850
DHW pre controller temperature
8851
8852 DHW consumption temp
8853 DHW instantaneous heater setpoint
Actual value of the swimming pool
8900
8901 Setpoint temperature swimming pool
8930 Pre controller actual value
8931 Pre controller setpoint
Segment flow temperature actual
8950
8951 Segment flow temperature setpoint
8952 Segment return temp
8957 Common flow set pre frig
8980 Buffer temp actual value top (B4)
8981 Buffer storage tank setpoint
8982 Buffer temp actual value bottom (B41)
8983 Buffer temp actual value middle (B42)
9000 Flow temperature setpoint H1
9001 Flow temperature setpoint H2
9005 Water pressure H1
9006 Water pressure H2
9031 State multifunctional relay (QX1)
State multifunctional relay (QX21
9050
State multifunctional relay (QX22
9051
State multifunctional relay (QX23
9052
State multifunctional relay (QX21
9053
State multifunctional relay (QX22
9054
