1.3 Cascade Slave Units
(150 Product Code 96.30000-7186)
(225 Product Code 96.30000-7187)
The Cascade Slave Unit is supplied without an integral low loss header and should
only installed where a Cascade Manager is also installed
A suitably sized low loss header must be installed within the system.
The system's (Secondary) circulating pumps (Heating / HWS) are to be connected
(hydraulically) to the external low loss header and not to the appliances flow and
return connections.
The Cascade Slave Unit is supplied without an integral RVS43 143 multiple unit
Cascade Manager and therefore relies on the presence of a Cascade Master Unit to
provide operational signals via the LPB communication wiring.
Integral
Distribution
Header.
