© MHG Heating Ltd
8.0 Hydraulic Design Single Unit (HT and HTP)
Electrical Connections Single Unit
If Direct On Boiler Weather Compensation is not required a 3000 Ohm Resistor must be applied to the AF terminals to remove the E10 Error Code from the RVS43 143
Cascade Manager LPB Network.
MHG Heating Ltd, Unit 4 Epsom Downs Metro Centre, Waterfield, Tadworth, Surrey, KT20 5LR
P:0845 6448802 F:0845 6448803
E:info@mhgheating.co.uk
W: www.mhgheating.co.uk
16
010617
