UL4000-D
ULTRA-LOK® TOOL
Operating Instructions
®
Cordless Ultra-Lok
Tool
BAND-IT IDEX, Inc.
Document # P09986 Rev. B
A Unit of IDEX Corporation
© Copyright
www.BAND-IT-IDEX.com
4799 Dahlia Street
BAND-IT IDEX, Inc. 2016
Denver, CO 80216-0307 USA
All Rights Reserved
P: 1-800-525-0758
F: 1-800-624-3925
1
Advertisement
Table of Contents
Related Manuals for Band-it UL4000-D
Summary of Contents for Band-it UL4000-D
-
Page 1: Operating Instructions
Operating Instructions ® Cordless Ultra-Lok Tool BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation © Copyright www.BAND-IT-IDEX.com 4799 Dahlia Street BAND-IT IDEX, Inc. 2016 Denver, CO 80216-0307 USA All Rights Reserved P: 1-800-525-0758 F: 1-800-624-3925... -
Page 2: Table Of Contents
Blade Change: Optional ½” Tool ....................15 BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation © Copyright www.BAND-IT-IDEX.com 4799 Dahlia Street BAND-IT IDEX, Inc. 2016 Denver, CO 80216-0307 USA All Rights Reserved P: 1-800-525-0758 F: 1-800-624-3925... -
Page 3: Warranty And Safety Guidelines
Metabo BS 18 LTX drills may result in unsatisfactory performance, hazards to the operator and/or the tool, or unsafe clamps. Disregard of this caution voids the warranty of the tool and releases BAND-IT of any and all liabilities arising from such misuses. -
Page 4: Setup Instructions
Only use 1/2" wide clamps when the optional 1/2" Shear Plate (BAND-IT # M09387) has been installed in the head in place of the 3/4" Shear Plate. See page 15 for ½” blade change procedure. -
Page 5: Band-It Idex, Inc
Drill Clutch during assembly, as shown above. BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation © Copyright www.BAND-IT-IDEX.com 4799 Dahlia Street BAND-IT IDEX, Inc. 2016 Denver, CO 80216-0307 USA All Rights Reserved P: 1-800-525-0758 F: 1-800-624-3925... -
Page 6: Tool Settings
Double Wrap *Preformed Band-It recommends hearing protection if this setting is used for an extended time. NOTE: These torque settings are suggested settings only; individual tools should be adjusted for the clamping application. Inspect lock per instructions on page 9-11. -
Page 7: Parts List
OSHA: 192.45 (h)(1) – Falling object protection BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation © Copyright www.BAND-IT-IDEX.com 4799 Dahlia Street BAND-IT IDEX, Inc. 2016 Denver, CO 80216-0307 USA All Rights Reserved P: 1-800-525-0758 F: 1-800-624-3925... -
Page 8: Exploded View
Tension Block Assembly Head Unit Figure 4 BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation © Copyright www.BAND-IT-IDEX.com 4799 Dahlia Street BAND-IT IDEX, Inc. 2016 Denver, CO 80216-0307 USA All Rights Reserved P: 1-800-525-0758 F: 1-800-624-3925... - Page 9 See page 6 for parts list Figure 6 BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation © Copyright www.BAND-IT-IDEX.com 4799 Dahlia Street BAND-IT IDEX, Inc. 2016 Denver, CO 80216-0307 USA All Rights Reserved P: 1-800-525-0758 F: 1-800-624-3925...
-
Page 10: Clamp Application: Free-End Clamps
Incorrect position of tool while tensioning while tensioning BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation © Copyright www.BAND-IT-IDEX.com 4799 Dahlia Street BAND-IT IDEX, Inc. 2016 Denver, CO 80216-0307 USA All Rights Reserved P: 1-800-525-0758 F: 1-800-624-3925... -
Page 11: Clamp Inspection
Tap down buckle shroud to complete clamp Figure 8 BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation © Copyright www.BAND-IT-IDEX.com 4799 Dahlia Street BAND-IT IDEX, Inc. 2016 Denver, CO 80216-0307 USA All Rights Reserved P: 1-800-525-0758 F: 1-800-624-3925... -
Page 12: Clamp Application: Preformed Clamps
Drill Dial to a lower number. 2. Drill clutch releases prematurely: Make sure Tool is fully seated on Drill (per page 4). If problem persists, contact BAND-IT technical support. 3. If tool does not cut off on initial setting: a. -
Page 13: Maintenance
1/2" long bead of lubricant. Remove Syringe, and actuate tool without a clamp a couple of times to spread lubricant evenly on tension screw. To order more lubricant, specify BAND-IT #C23199 2. Every 500-1000 clamps, depending on torque setting, inspect and repack front bearing with same lubricant. - Page 14 Tool Body side. Reinstall Blade and tighten the Blade Mounting Screws approximately 120 in-lbs. Reattach Tool Adapter to Ultra-Lok Tool. Reattach Tool to Drill and drive Tension Block all the way forward. Note: Drills needing repair must be returned to Band-It. BAND-IT IDEX, Inc. Document # P09986 Rev. B A Unit of IDEX Corporation ©...
-
Page 15: Blade Change: Optional ½" Tool
6. Re-attach Drill to Tension Body making sure the Drill and Tension Body are properly aligned, and tighten the single Blade Cap Screw located on the Adapter Collar. 7. These tools are NOT designed to work with traditional band and buckle designs. BAND-IT Ultra-Lok clamps must be used. 1/4" Ball (M06587) Blade Cap Screw (M05787) Qty.
