Quick Description Of The Features - MyTek WORKSTATION24 AD/DA Owner's Manual

Workstation AD/DA is more than just a digital audio converter. It is a complete front end for you computer
workstation. We will call it here "the Interface". The chart below and on the next page explains the basic
setup and functions of the interface. On the next pages you will find diagrams of the signal flow and basic
steps for a quick start.
WORKSTATION24 AD/DA
24 BIT PERFORMANCE DAW INTERFACE
ADC
SYNC
EXT.DIG. COMP.DIG. EXT.WCK
LOCK
IN LOCK IN LOCK
48kHz
44.1kHz
Sets the
sampling of
the ADC and
control bits on
all digital outs.
Must be always
set right for
digital transfers.
The leds indicate lock
to a particular
signal clock.
NOTE: All outputs are muted if:
1. external clock is selected but not present.
2. Digital input with no input signal is selected.
This is done on purpose to avoid interference of unsynchronized clocks which could degrade the sonic
performance of the interface.

1. Quick description of the features.

the converter's
self-calibration.
Turn it off/on to
reset the converter.
There is a 5 secs delay
before the interface starts
to operate after the power up.
Power off/on to reset the unit.
OUTPUT LEVEL
SAMPLING HiBit16
ON L
-20 dB
OFF
Led shows
peak value
of the analog
and "ext.dig."
outs.
Adjusts the
HiBit16
converts
output level.
24 bit to 16 bit.
Use only when going
(Chapt.3)
to 16 bit media.
(Chapt.8)
POWER ON
Turns the
power on
and initiates
R
analog
MONITOR
&
DIG OUTS
INPUT
AES/EBU INPUT
EXT. DIGITAL
S/PDIF
ANALOG COMPUTER
Selects the input
which then is
present on the
analog and all
digital outputs.
Takes out
the computer
from the signal
path.
(See Chapt.6
"stand alone")
INPUT LEVEL
L R
OVER
-20 dB
Meter
shows peak
value of the
ANALOG
input.
Adjusts the
analog
input level.
(Chapt. 3)
ADC
SYNC
EXT.DIG. COMP.DIG.
IN LOCK IN LOCK
EXT.WCK
INTERNAL
Sets the clock
reference.
Set it to "Int"
unless you are
using ext.
wordclock sync
(Chapt.7)
