MyTek WORKSTATION24 AD/DA Owner's Manual page 11

Multichannel operation. You can daisy-chain several interfaces in order to get more channels. Let's say you
want 8 channels of input/output for your Sonic Solutions station. You will need 4 Workstation AD/DA
interfaces and 3 BNC type 75 Ohm cables. You will also need 2 "T" BNC type adapters (Radio Shack).
First interface is the master and the rest are slaves. If you are doing sound for picture you may sync the first
unit to video as on the previous page.
You could also daisy chain the units wordclocks but we recommend using the "T" adaptor for more stable
clock. The wordclock output of the interface can drive up to 15 LS TTL loads. The wordclock input is one LS
TTL load.
The interface outputs wordclock only if "analog input" is selected.
WORDCLOCK IN WORDCLOCK OUT
110
WORDCLOCK IN WORDCLOCK OUT
110
WORDCLOCK IN
WORDCLOCK OUT
110
WORDCLOCK IN WORDCLOCK OUT
110
10
