Lock Inspection Systems MET 30+ Operating Manual page 41

Doc. Ref.No: Q875-0143/ENG
Pressing SELECT results in the following display:
The key should be pressed to give the message "Reset reject and product
counts? Yes" and the SELECT key pressed.
8.1.3 Typical Output
The output from the printer gives a summary of the metal detector's status and
product setup, followed by a list of reports. A report consists of a time stamp and a
message.
A typical printout is as follows:
Lock Inspection Systems
Product and status report at
Id string of detector – 89235/1 95x38 1MHZ
Current product - PILLS
Reject count -
Product settings:
Name
0 TEST SETUP
1 PRODUCT A
2 PILLS
3 CAPSULES
-- End of product settings --
02/01/07 8:00:15 PRODUCT A
02/01/07 8:03:23 PRODUCT A
02/01/07 8:05:39 product selected [2] PILLS
02/01/07 8:07:48 PILLS
02/01/07 8:07:55 PILLS
02/01/07 8:10:08 PILLS
02/01/07 8:14:21 PILLS
02/01/07 8:18:27 PILLS
02/01/07 8:28:17 PILLS
02/01/07 8:56:35 test started
02/01/07 8:56:35 operator 0000
02/01/07 8:56:38 TEST FAILED
02/01/07 8:56:44 test started
02/01/07 8:56:44 operator 1234
02/01/07 8:56:49 test passed
02/01/07 8:56:43 PRODUCT A
File Name: Q875-0143 ENG Iss2 Met30+ Operating.doc
Issue 2
Reset reject and
Product counts? No
12
gain height
H (500)
H (150)
H (710)
H (800)
Met 30+ Operating Manual
02/01/07 9:42:31
width phase delay
100 0.0 1.00s
120 13.4 1.00s
100 95.0 0.32s
105 58.4 1.00s
S 156 P 68.0
S 200 P 76.3
S 227 P 130.3
S
S 221 P 2.1
S 224 P 3.4
S 121 P 2.1
S 324 P 0.2
S 127 P 12.8
12/01/10
reject
0.50s
0.50s
0.50s
0.50s
51 P 37.9
Page 39 of 58
