6. OPERATION CHART

6.1 Met30 + 1f System Menu

OR
Product/reject counts
Product setup data
Edit Product Menu
[E] Edit product name
[W] Product Width
[H] Product Height
[P] Product Phase
[G] Adjust gain
[x] Exit
Configure System
Inputs
Syschek
Aux
Exit
File Name: Q875-0143 ENG Iss2 Met30+ Operating.doc
Issue 2
SELECT
Enter Security Code
Supervisor Menu
[T] Do Sample test
[P] Select Product
[R] Print reports
[C] Clear counts
[S] Setup product
[r] Adjust Reject Timer
[E] Edit product
[D] Delete product
[o] Operator's code
[e] Engineering setup
[x] Exit
Engineering Setup Menu
[S] Sample test reminder
[c] Configure system
[v] Vibration setup
[T] Set system clock
[C] Communication setup
[P] Printer setup
[s] Supervisor's code
[e] Engineer's code
[l] Lock engineering
[x] Exit
Met 30+ Operating Manual
Operator Menu
Test
Product
Print
Exit
12/01/10
SELECT
Engineering displays
Software version
Machine type
Timer parameter
Syschek time (only if
configured)
Noise test
Test Tacho (only if
configured)
Communication
Setup
Port A
Port B
Detector ID
Exit
