Supervisor Menu - Lock Inspection Systems MET 30+ Operating Manual

Doc. Ref.No: Q875-0143/ENG
option is used the 'Print' option is selected by the
When this is done the display shows 'Printing report' and 'SELECT to end print'.
Pressing the SELECT key stops the print out. The report can be re-printed by
selecting the 'Print' option again. No reports can be cleared from this menu.
5.3.4 Exit
Select this to return to the normal running display.

5.4 Supervisor Menu

The supervisor menu looks like:
The display is shown with one of the letters flashing, the text will change depending
on which letter is selected. The
right. The letters have the following meanings:
T = Do sample test
C = Clear counts
E = Edit product
e = Engineering setup
5.4.1 Do Sample Test (T) :
Same as Test option in the operator menu.
5.4.2 Select Product (P) :
Same as Product option in the operator menu.
5.4.3 Print Report (R) :
Same as the Print option in the operator menu but this time when the reports have
been printed Clear records ? No is displayed. The default is "No" but this can be
changed to "Yes" by either the '
and returns to the supervisor menu.
5.4.4 Clear Counts (C) :
Use this option to clear the reject and product counts to zero. Note that product
counting is only reliable for a product that completely breaks the photocell light beam
once.
File Name: Q875-0143 ENG Iss2 Met30+ Operating.doc
Issue 2
Met 30+ Operating Manual
TPRCSrEDoex
Do sample test
key cycles the letter to the left and the
P = Select product
S = Setup product
D = Delete product
x = Exit.
' or ' ' key. The SELECT key is then pressed
or keys then the SELECT key.
R = Print report
r = Adjust reject timers
o = Operator's code
12/01/10
key to the
Page 21 of 58
