Lock Inspection Systems MET 30+ Operating Manual page 24

Doc. Ref.No: Q875-0143/ENG
5.4.5 Setup Product (S) :
The display initially requests selection between set up for a new product or
adjustment of an old product. Use
SELECT to confirm the selection.
5.4.5.1 New Product
If "New product" is selected, a product name must be entered. This is done by
scrolling through the alphabet with the
appears on the display press SELECT. The sequence of selectable characters is as
follows:
ABCDEFGHIJKLMNOPQRSTUVWXYZ 0123456789. /#<♦
If a mistake is made press the
SELECT, to move back to the previous character. When the full name has been
entered press SELECT with the diamond '
names may be up to 20 characters in length.
5.4.5.2 Adjust Old Product
If "Adjust old product" is selected scroll through the list of products and select one, in
the same way as the product option in the operator menu.
5.4.5.3 Automatic/Manual Setup
After choosing a name for a new product setup or selecting an old product to adjust,
a choice is displayed between doing an automatic or a manual setup:
It is not recommended to do a manual setup, this is primarily for testing by service
engineers. Press SELECT to proceed with an automatic product setup and the
display should change to:
The product should then be passed through the aperture, as it would be during
production, until the setup parameters are displayed. Various messages are
displayed while the automatic setup is taking place, as an indication of what the
software is doing.
File Name: Q875-0143 ENG Iss2 Met30+ Operating.doc
Issue 2
Met 30+ Operating Manual
/ to move the position of the arrow and
New product
Adjust old product
/
/ keys until a '<' is displayed and then press
♦
' displayed, to finish name entry. Product
Automatic
Manual
Gain = High
Pass product 1
keys. When the desired character
12/01/10
Page 22 of 58
