Summary of Contents for Hay COPENHAGUE TABLE
- Page 1 > I N ST R U C T I O N S M A N U A L < C O P E N H A G U E TA B L E C P H 3 0 B y R O N A N & E R WA N B O U R O U L L E C...
- Page 2 > I N T R O D U C T I O N < Copenhague is a furniture series designed by Ronan and Erwan Bouroullec designed especially for the University of Copenhagen in 2013. In addition to a homely and welcoming expression, functionality, durability and ease of cleaning were important design requirements for the university.
- Page 3 > C A R E A N D M A I N T E N A N C E < > C A R E A N D M A I N T E N A N C E < CAUTION LACQUERED OR STAINED WOOD LINOLEUM...
- Page 4 > C O N T E N TS < PAGE 8 - 19 L200/250/300 x W90 x H74 cm L200 x W80 x H105 cm PAGE 20 - 31 L250/300 x W120 x H74 cm...
- Page 5 > L 2 0 0 / 2 5 0 / 3 0 0 x W 9 0 x H 74 c m • L 2 0 0 x W 8 0 x H 1 0 5 c m < > PA R T S < A x 1 B x 4 C x 12...
- Page 6 While assembling, keep the table inside the cardboard box with edge foam to protect the Place 2 of the C parts in the shown holes. Make sure that the thread tabletop from scratches etc. Make sure that all parts are included. is pointing upwards and that the holes are facing each other.
- Page 7 Place 1 of the D parts in the shown holes. Make sure that the Drop 2 of the E parts in the shown holes and make sure to hit the D parts’ tapered holes are pointing upwards. tapered holes. Gently tighten all 4 E parts little by little with the Allen key. Tighten both of the E parts completely.
- Page 8 Place 4 of the C parts in the shown holes. Make sure that the thread Place 2 of the D parts in the shown holes at the same time. is pointing upwards and that the holes are facing each other. Make sure that the tapered holes are pointing upwards.
- Page 9 Drop 4 of the E parts in the shown holes and make sure to hit the Tighten all E parts completely. Repeat step 6 - 8 at the other end of the table. D parts’ tapered holes. Gently tighten all E parts little by little.
- Page 10 1 1. Use a proper screwdriver to fasten part F in the remaining free holes in the frame. Flip the table (2 persons recommended).
- Page 11 > L 2 0 0 / 2 5 0 / 3 0 0 x W 1 2 0 x H 74 c m < > PA R TS < B x 4 A x 1 C x 2 D x 16 Ex 8 F x 16 G x 16...
- Page 12 While assembling, keep the table inside the cardboard box with edge foam to protect the Place 4 of the D parts in the shown holes. Make sure that the thread tabletop from scratches etc. Make sure that all parts are included. is pointing upwards and that the holes are facing each other.
- Page 13 Place 2 of the E parts in the shown holes. Make sure that the Drop 4 of the F parts in the shown holes and make sure to hit the E parts’ tapered holes are pointing upwards. tapered holes. Gently tighten all 4 F parts little by little with the Allen key. Tighten both all F parts completely.
- Page 14 Place 4 of the D parts in the shown holes. Make sure that the thread Place 2 of the E parts in the shown holes at the same time. is pointing upwards and that the holes are facing each other. Make sure that the tapered holes are pointing upwards.
- Page 15 Drop 4 of the F parts in the shown holes and make sure to hit the Tighten all F parts completely. Repeat step 6 - 9 at the other end of the table. E parts’ tapered holes. Gently tighten all F parts little by little.
- Page 16 1 1. Use a proper screwdriver to fasten part G in the remaining free holes in the frame. Flip the table (2 persons recommended).
- Page 19 Havnen 1 8700 Horsens Denmark +45 4282 0282 / hay@hay.dk ITEM NO. 706307 5 710441 206583...
