Athina - 1000 Wall Unit
Assembly Instructions -
Dimensions
Width - 100cm
Depth - 29cm
Height - 70cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
608/0842
608/0969
608/0907
608/1023
608/3014
MADE IN
BRITAIN
Issue 3 - 03/02/14
Advertisement
Related Manuals for Argos Athina 1000 Wall Unit
Summary of Contents for Argos Athina 1000 Wall Unit
- Page 1 Athina - 1000 Wall Unit Assembly Instructions - 608/0842 Please keep for future reference 608/0969 608/0907 608/1023 608/3014 Dimensions Width - 100cm Depth - 29cm MADE IN Height - 70cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 3 - 03/02/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 23kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Top/Base (D0333A) (970 x 269mm) Side Shelf (D0331A) (D0334A) (969 x 197mm) (700 x 290mm) 5 Back Door...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the left side Use one of the side panels to make the left side. Fit 2 hinge plates onto the left side making sure that the slot Front...
- Page 6 Assembly Instructions Step 2 Prepare the right side Use one of the side panels to make the left side. Fit 2 hinge plates onto the right side making sure that the slot is facing towards the Front front edge. edge This is the right side Fit a hanging bracket...
- Page 7 Assembly Instructions Step 3 Prepare the top and base 10mm Insert 4 large locking nuts into the 2 top/base panels shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 2 wooden dowels into the 2 top/base panels as shown.
- Page 8 Assembly Instructions Step 5 Prepare the munting Tap 2 wooden dowels into the munting shown. Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels. Step 6 Fit the munting Fit the munting to the top and base panels...
- Page 9 Assembly Instructions Step 8 Fit the back The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
- Page 10 Assembly Instructions Step 9 Note: The diagrams show the wall brackets with 3 holes. They can also be supplied with just 2 holes. Fit the unit to the wall To fix the unit to the wall, 18mm 18mm place the unit in the 964mm required position and 37mm...
- Page 11 Assembly Instructions Step 10 Insert the shelf studs Push 4 shelf studs into the holes in the side panels at the desired height. Step 11 Manouvre the shelf into the unit and onto the shelf studs Step 12 Prepare the doors Push fit 2 hinges into each of the 2 doors...
- Page 12 Assembly Instructions Step 13 Drill the handle holes in the door This will be ONLY drill Important: Please follow the left door these instructions these 2 holes carefully. Lay the doors down onto a smooth surface. Important: Check that the holes and hinges are in the same place as the diagrams.
- Page 13 Assembly Instructions Step 14 Fit doors and handles screw A 2 people are needed here Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinges. screw B Push the hinge onto the front part of the hinge plate Keep the hinge...
- Page 14 Assembly Instructions Step 15 Adjust the door if needed Height adjustment. Loosen screws A on hinge plates and move door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on hinge plate and move door in or out as required.
- Page 15 Lift with care. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 16 ALR2461...
