Page 2
HWg-STE – manual HW group www.HW-group.com Page 2...
Page 3
HWg-STE – manual HW group HWg-STE connections LED indicators Green: Power & Mode Yellow: Link & Activity POWER input ETHERNET SENSORS 5VDC supply 100 Mbps S1 and S2 ports for connecting Use the supplied power adapter temperature or humidity sensors.
HWg-STE – manual HW group Recommended connections Forwarding alarms to SMS (via the Email-2-SMS service): Sensor connection options: www.HW-group.com Page 4...
Page 5
Connect the unit to the Ethernet (patch cable to a switch, or a cross-over cable to a PC). Plug the power adapter in to a power outlet and connect it to the HWg-STE power connector. The green Power & Mode LED in the RJ45 connector lights up.
HWg-STE – manual HW group First steps 3) WWW interface of the device To open the WWW interface of the device: Enter the IP address into a web browser Click the IP address in UDP Config Click the underlined IP address in UDP SETUP The WWW page displays current states of inputs and outputs.
HWg-STE – manual HW group Product configuration Device name Identifies the device in e-mail and SNMP User-defined footer. For example, administrator's contact details Unit of temperature, for display and alarm inputs Password to access device configuration www.HW-group.com Page 7...
Page 8
HWg-STE – manual HW group SNMP Port for SNMP polling SNMP device identification, equal to device name Email SMTP server to use for sending e-mail Sends a test e-mail to all configured recipients www.HW-group.com Page 8...
Page 9
HWg-STE – manual HW group Time Sensors Deletes the sensor from the list - Scans for changes in connected sensors www.HW-group.com Page 9...
Page 10
HWg-STE – manual HW group Graph Graf is available in firmware 1.0.12 or higher Choose shown sensor. Values stored in RAM memory. Value samples period for the graph Value graph. Mouse cursor show time Save Range for the and value of the sample.
Page 11
HWg-STE – manual HW group System List of SNMP variables Firmware update www.HW-group.com Page 11...
Remote monitoring of input states and the temperature sensor Power supply HWg-STE: +5V / 250 mA HWg-STE PoE: +5V / 250 mA (adaptor) or PoE IEEE 802.3af (Power over Ethernet) Dimensions: 65 x 80 x 30 [mm] LED indicators in the RJ45 connector Green: Power / Status ...
