Page 1: Assembly Instructions
Assembly instructions Art.-Nr.: 115 0780 257 7119 Sport-Thieme Aluminium ® Football Goal 7.32x2.44 m, with Welded Corners, Socketed D-38367 Grasleben · Germany sport-thieme.com · info @sport-thieme.com Phone: +49 53 57 181 543 · Fax: +49 53 57 181 921... -
Page 2: Scope Of Delivery
Assembly instructions for Art.-Nr. 115 0780/257 7119 1. Scope of delivery Please check the following content before assembly. Content: 1x crossbar, length 5.90m 2x upright, length 2.23m 2x corner connection, length 0.81 / 0.81m 2x ground socket 2x cap for ground sockets... - Page 3 Assembly instructions for Art.-Nr. 115 0780/257 7119 2. Assembly of the goal We recommend to mount the goal on the grass or on a suitable surface to avoid damages of the profiles. a) Lay goal profiles on the ground. Then stick uprights and crossbar on corner connection elements (should it be difficult to stick connection elements into the profiles we recommend to use a screw clamp and press the profile inward carefully so that connection elements easily slide into the profile).
- Page 4 Assembly instructions for Art.-Nr. 115 0780/257 7119 c) Place at both net hoops net hoop braces with rounded fitting above the bore hole in the net hoop and fix with hexagonal screw DIN 912 M6 x 40, washer DIN 9021, 7.4 x 22 mm und nut DIN 985, M6.
- Page 5 Assembly instructions for Art.-Nr. 115 0780/257 7119 3. Installation of ground sockets a) Stick ground sockets on the uprights. Erect the goal. To avoid slipping of the ground sockets during fixing and concreting join uprights and ground sockets by means of the wedges. Let the flat aluminium wedge (50 x 5mm, length 435 mm) slide into the guiding groove.
- Page 6 Assembly instructions for Art.-Nr. 115 0780/257 7119 c) After concrete set (approx. 1-2 days) nets can be fixed. d) The goals can always be taken out of the ground sockets after having removed the special wedges. Stick a screw driver in the borehole of the wedge and pull it out (see also picture of point 3a).
