Control connection data

External power supply
+24 V DC output
(Term. 10)
Digital inputs DI1...DI6
(Term. 13...18)
Maximum power:
Frames R1...R5: 25 W, 1.04 A at 24 V AC/DC ±10%
with an option module
Frames R6...R9: 36 W, 1.50 A at 24 V AC/DC ±10% as
standard
Supplied from an external power supply through option
module CMOD-01 or CMOD-02 with frames R1...R5. With
frames R6...R9 no options are needed.
Terminal size:
Frames R1...R5: 0.2...2.5 mm
Frames R6...R9: 0.14...2.5 mm
Total load capacity of this outputs is 6.0 W (250 mA / 24 V)
minus the power taken by the option modules installed on
the board.
Terminal size:
Frames R1...R5: 0.2...2.5 mm
Frames R6...R9: 0.14...2.5 mm
Input type: NPN/PNP
Terminal size:
Frames R1...R5: 0.14...1.5 mm
Frames R6...R9: 0.14...2.5 mm
DI1...DI5 (Term.13...17)
12/24 V DC logic levels: "0" < 4 V, "1" > 8 V
R : 3 kohm
in
Hardware filtering: 0.04 ms, digital filtering: 2 ms sampling
DI5 (Term.17)
Can be used as a digital or frequency input.
12/24 V DC logic levels: "0" < 3 V, "1" > 8 V
R : 3 kohm
in
Max. frequency 16 kHz
Symmetrical signal (duty cycle D = 0.50)
DI6 (Term. 18)
Can be used as a digital or PTC input.
Digital input mode
12/24 V DC logic levels: "0" < 4 V, "1" > 8 V
R : 3 kohm
in
Hardware filtering: 0.04 ms, digital filtering: 2 ms sampling
Note: DI6 is not supported in the NPN configuration.
PTC mode – PTC thermistor can be connected between
DI6 and +24VDC: < 1.5 kohm = '1' (low temperature), >
4 kohm = '0' (high temperature), open circuit = '0' (high
temperature).
DI6 is not a reinforced/double insulated input. Connecting
the motor PTC sensor to this input requires usage of a
reinforced/double insulated PTC sensor inside the motor.
