1.0 Introduction
lECON- F(GC)/F(4C) is an Engine Control / Protection Unit for engines
used for NON DG applications.
lThe controller can measure signals from either MPU or charging
alternator to calculate RPM.
lECON provide choice of Varity of sensor selection from predefined
selection chart
lIn critical operation it is possible to disable or debar tripping of engine via
an external digital input.
l128x64 pixel graphical display enhance convenience in configuration of
controller.
2.0 Protection, Supervision Salient Features

Protection

Low Lube Oil Pressure(LLOP)
l
High Water Temp. (HWT)
l
Fuel Level
l
Emergency off
l
Oil Temperature .
l
Charging Alternator Fail/V-Belt failure
l

Display and Measurement

Battery Voltage
l
Engine Run Hour
l
RPM
l
Oil Pressure in KG/cm2
l
Water Temp in degree centigrade
l
Oil Temp in degree centigrade
l
Fuel Level in %
l
Service Hour
l

3.0 Digital Output

Seven digital output (Six negative and one positive) are available, four
output contacts programmable
.
Start/Crank (Battery Negative)
l
Charging Alternator (Battery positive)
l
Solenoid (Battery Negative)
l
Annunciation 1 (Battery Negative)
l
Annunciation 2 (Battery Negative)
l
Annunciation 3 (Battery Negative)
l
Annunciation 4 (Battery Negative)
l
Hooter (Battery Negative)
l
Operating Instructions
[In ECON-F(4C)only]
[In ECON-F(4C)only]
Page - 2
