• 2.0 Salient Features, Protection and Supervision
• Mains Measurements
◦ 1 Phase/ 3 Phase Voltage
◦ 1 Phase/ 3 Phase Current
◦ Frequency
◦ PF, KW, KVA,
• Generator Measurements
◦ 1 Phase / 3 Phase Voltage
◦ 1 Phase / 3 Phase Current
◦ Frequency
◦ PF, KW, KVA, KWH .
◦ Battery Voltage
◦ Water Temperature
◦ Oil Pressure
◦ Fuel Level
◦ RPM
◦ Run Hour
◦ Service Due Hour
• Protection / Supervision Mains
◦ Under/Over Voltage
◦ Under/Over Frequency
◦ Phase Sequence
◦ Voltage Unbalance
◦ Overload
• Protection / Supervision DG
◦ Under/Over Voltage
◦ Under/Over Frequency
◦ Current Unbalance
◦ Over Speed
◦ RWL
◦ LLOP
◦ HWT
◦ LFL
◦ Charging Alternator/V-belt
◦ Emergency off
◦ Service Due
◦ Fail To Start
◦ Fail To Stop
• Digital Input : 10 digital [3 fixed, 4 programmable, 3 programmable (optional)]
• Output: 9 digital
