Procom ECON-F Installation Manual page 13

Ann oil 1: No Annunciation
temp 2:On DO Ann1
fault 3:On DO Ann2
4:On DO Ann3
5:On DO Ann4
Ann 1: No Annunciation
Fuel 2:On DO Ann1
Fault 3:On DO Ann2
4:On DO Ann3
5:On DO Ann4
Ann 1: No Annunciation
HWT 2:On DO Ann1
Fault 3:On DO Ann2
4:On DO Ann3
5:On DO Ann4
Ann 1: No Annunciation
LLOP 2:On DO Ann1
Fault 3:On DO Ann2
4:On DO Ann3
5:On DO Ann4
Ann 1: No Annunciation
RPM 2:On DO Ann1
Fault 3:On DO Ann2
4:On DO Ann3
5:On DO Ann4
Announce 1: No Annunciation
Unit 2:On DO Ann1
OK 3:On DO Ann2
4:On DO Ann3
5:On DO Ann4
D.
Device Id Modbus device ID
Baud Rate RS 485 Communication Baudrate
Operating Instructions
If desired, the oil temp fault can
be announced at one of the
annunciation Digital Output.
If desired, the Low Fuel fault
can be announced at one of the
annunciation Digital Output.
If desired, the High water
temperature fault can be
announced at one of the
annunciation Digital Output.
If desired, the LLOP fault can
be
announced at one of the
annunciation Digital Output.
If desired, the Over/Under
speed fault can be announced
at one of the annunciation
Digital Output.
If desired, the healthiness of the
controller can be announced at
one of the annunciation Digital
Output
RS-485 Parameter #
No
Annun-
ciation
No
Annun-
ciation
No
Annun-
ciation
No
Annun-
ciation
No
Annun-
ciation
No
Annun-
ciation
1 1-247
9600 1200
2400
4800
9600
19200
Page - 12
