9.2 Low Fuel Sensors Data :

S.No. Fuel in %
1 0
2 5
3 10
4 17
5 20
6 25
7 30
8 35
9 40
10 45
11 50
12 55
13 60
14 65
15 70
16 75
17 80
18 85
19 90
20 95
21 100
Operating Instructions
Type A Sam_0
0 14
5 18
10 22
17 29.5
34 37
51 55.5
68 74
85 92
102 110
110.5 124.5
119 139
127.5 149
136 159
144.5 165
153 171
157.7 172.5
162.3 174
167 176
171.7 178
176.3 181
180 184
Resistance in ohms
Sam_1
Electronics
10
18.5
27
35.5.
44
52.5
61
69.5
78
86.5
95
103.5
112
120.5
129
137.5
146
154.5
163
171.5
180
Linear
10 10
19.5 18.5
29 27
38.5 35.5
48 44
57.5 52.5
67 61
76.5 69.5
86 78
95.5 86.5
105 95
114.5 103.5
124 112
133.5 120.5
143 129
152.5 137.5
162 146
171.5 149.5
181 153
190.5 166.5
200 180
