- Page 1 Assembly and operating instructions TFWS7PULL03.01 Cable pull TF-WS7-PULL...
- Page 2 Cable pull WS7...
- Page 3 Dear Customer, Thank you for deciding for a high-quality training equipment of the brand Taurus, the brand that makes athlete‘s hearts beat faster. Taurus offers a wide range of home fitness equipment like elliptical cross trainers, ergometers, treadmills and rowing machines.
- Page 4 Cable pull WS7...
-
Page 5: Table Of Contents
CONTENTS GENERAL INFORMATION 1.1 Technical data ASSEMBLY ORDERING SPARE PARTS 3.1 Service hotline 3.2 Serial number and model name 3.3 Parts list 3.4 Exploded drawing... -
Page 6: General Information
Packed dimensions (length x width x height): approx. 1935 mm x 420 mm x 215 mm Set-up dimensions with Multi-gym WS7 (length x width x height): approx. 225 cm x 172 cm x 213 cm Maximum user weight: 150 kg/330 lbs Cable pull WS7... -
Page 7: Assembly
ASSEMBLY We recommend that you do not completely tighten the screws and bolts at first in order to make the assembly of the training machine easier. However, please make sure that all screws and bolts are tightened once the assembly is done. Screws and cables overview... - Page 8 Cable pull WS7...
- Page 9 Step 1: Exploded drawing Description Note Qty. washer Φ12 lock nut connection plate spring washer Φ12 hexagon bolt M12*30 hexagon bolt M12*80 connection tube pull cable tower back connection tube side ground frame...
- Page 10 (20), M12 lock nuts (21), and the connecting plate (128) on the main frame. 3. Mount the lateral main frame (166) with four screws M12*80 (132), M12 washers (20), M12 lock nuts (21), and connecting plates (128) on the front and rear connecting tube. Cable pull WS7...
- Page 11 Step 2: Exploded drawing No. Description Note Qty. No. Description Note Qty. washer Φ10 guide tube washer Φ12 side standing tube lock nut side elbow tube lock nut hexagon bolt M10*70 arc-shaped hexagon bolt M12*30 hexagon bolt M12*80 sliding sleeve T shape pull pin Φ10...
- Page 12 (20), and the connecting plate (129) on the lateral main frame. 4. Mount the lateral angled tube (171) with M12*30 screws (131), M12 washers (20), and M12 lock nuts (21) on the lateral standpipe (170) and the right cover. Cable pull WS7...
- Page 13 Step 3: Exploded drawing Description Note Qty. washer Φ10 lock nut hexagon bolt M10*75 pull cable tower pulley Φ14*50 pull cable tower cover pull cable tower cover...
- Page 14 (5), and M10 nuts (23) on the guide rod, lateral standpipe, and lateral angled tube. 2. Mount the M14*50 shafts (172) with M10*75 screws (65), M10 washers (5), and M10 nuts (23) on the covers of the cable tower (173, 174). Cable pull WS7...
- Page 15 Step 4: Exploded drawing Description Note Qty. washer Φ10 lock nut hexagon bolt M10*45 pulley Φ95*26 hexagon bolt M10*80 pulley spacer Φ20*Φ...
- Page 16 1. Mount three pulleys (55) with M10*80 screws (175), M10 washers (5), and M10 nuts (23) on the marked points between the covers of the cable tower. 2. Mount the pulley (55) with a M10*45 screw (52), M10 washer (5), and M10 nut (23) below the lateral main frame. Cable pull WS7...
- Page 17 Step 5: Exploded drawing Description Note Qty. washer Φ10 lock nut hexagon bolt M10*25 hexagon bolt M10*45 pulley Φ95*26 cable hook hexagon bolt pulley catch plate M10*50 movable pulley frame pull cable tower short L:5625mm...
- Page 18 Step 5: Exploded drawing TF-WS7-PULL TF-WS7-ATT Cable pull WS7...
- Page 19 Step 5: Assembly 1. Replace the cable (70) of step 13 by the cable (179). Pull the cable (179) through the same guiding path like in step 13. Mount the flat, short cable end of the cable tower (179) with M10*25 screw (30), M10 washer (5), and M10 nut (23) on the lateral main frame.
- Page 20 Step 6: Exploded drawing Description Note Qty. washer Φ10 lock nut hexagon bolt M10*25 9 link chain & snap hook handle belt pull cable tower long L:7290mm Cable pull WS7...
- Page 21 Step 6: Exploded drawing...
- Page 22 4. Mount the end of the ball-shaped head back again on the cable. 5. Hang nine link chains and snap hooks (60) with one end on the hand strap (85) and with the other end on the long cable of the cable tower (180). Cable pull WS7...
-
Page 23: Ordering Spare Parts
ORDERING SPARE PARTS Service hotline So that we can give you the best possible service, please have your model name, part number, serial number, exploded drawing and parts list ready. SERVICE-HOTLINE 80 90 16 50 +49 4621 4210-0 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-699 +49 4621 4210-933... -
Page 24: Parts List
M12*125 hexagon bolt M10*50 connection tube pull cable tower back connection tube side ground frame sliding sleeve T shape pull pin Φ10 guide tube side standing tube side elbow tube pull cable tower pulley support tube Φ14*50 Cable pull WS7... - Page 25 Description Dimensions Qty. pull cable tower cover left pull cable tower cover right hexagon bolt M10*80 pulley spacer Φ20*Φ10.5*19.5 pulley catch plate movable pulley frame pull cable tower short cable L:5625mm pull cable tower long cable L:7290mm powder metallurgy sleeve Φ33*Φ20*18 stationary shaft Φ20*74*M10...
-
Page 26: Exploded Drawing
Exploded drawing Cable pull WS7... - Page 27 DISCLAIMER ©2011 TAURUS is a registered brand of the company Sport-Tiedje GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Sport-Tiedje is prohibited. Product and instructions are subject to change. Technical data can be changed without advance notice.
- Page 28 Cable pull...
