- Page 1 Fast EthErnEt OFFicE switch usEr manual Model 503433 INT-503433-UM-1207-01...
- Page 3 Thank you for purchasing the INTELLINET NETWORK SOLUTIONS ™ Ethernet Media Converter, Model 503443. Designed for high performance in an environment where network traffic and the number of users increases continuously, this compact switch provides smooth network migration and allows easy upgrades to match network capacity.
- Page 4 cOnnEctiOns & indicatOrs LEDs The front panel LED indicators provide at-a-glance network status and real-time connectivity info, as detailed in the chart below. Status Operation Power Green The switch is on. Power is disconnected. Link/Act Green Valid port connection; ready to transmit/receive. Flashing Data is being transmitted or received.
- Page 5 Power Power is supplied to the Fast Ethernet Office Switch through an external 7.5 V DC power adapter that connects to the device through the side panel. installatiOn The Fast Ethernet Office Switch can be placed on a desktop or other appropriate flat surface.
-
Page 6: Specifications
spEciFicatiOns Standards • IEEE 802.3 (10Base-2 Ethernet) • IEEE 802.3 (10Base-T Ethernet) • IEEE 802.3u (100Base-TX Fast Ethernet) • IEEE 802.3x (flow control for full duplex mode) General • Media support: - 10Base-2 RG-58 A/U 50 Ohms coaxial cable - 10Base-T Cat3, 4, 5 UTP/STP RJ-45 - 100Base-TX Cat5 UTP/STP RJ-45 •... - Page 8 INTellINeT NeTWoRK SolUTIoNS offers a complete line ™ of active and passive networking products. Ask your local computer dealer for more information or visit www.intellinet-network.com Copyright © INTELLINET NETWORK SOLUTIONS All products mentioned are trademarks or registered trademarks of their respective owners.
