KB1
Precise setting view
Double Click on the knobs to open a small interface dedicated to the precise
setting of the corresponding knob value. To close the Precise Setting View click
on the OK Button (6).
J1) Increment Button A for Filter
Frequencies = increment by hundreds,
everything else = increment by units.
J2) Increment Button B for Filter
Frequencies = increment by tens,
everything else = increment by
tenths.
J3) Decrement
Filter Frequencies
by hundreds, everything else =
decrement by units.
J4) Decrement Button B for Filter Frequencies = decrement by tens, everything
else = decrement by tenths.
J5) Value Textbox can be edited to directly write the desidered Knob value.
J6) OK Button sets the number inside the text box as value of the parameter
controlled by the corresponding knob and closes the Precise Setting View.
40
Button A for
= decrement
J2
J1
J3
J5
J6
J4
img. J
