K-array KB1 User Manual page 33

D1) Channel Preset Name Display shows the name of the preset currently
loaded on the channel.
D2) Channel Preset Selector opens and closes Channel Preset Window
(see img.
D3) Compressor Window Button opens and closes the Channel Compressor
Window (see
D4) EQ Window Button opens and closes the Channel EQ Window (see
D5) Filter Type Selectors select the type of filter from three options: Low
Shelving, Peak/Notch and High Shelving.
D6) Filter Frequency Knobs set the central or corner frequency of the
corresponding filter.
D7) Filter Gain Knobs set the gain (positive or negative) of the corresponding filter.
D8) Filter Q / Slope Knobs set the "Q" or "Slope" value of the corresponding filter.
D9) AUX Send Knob regulates the amount of pre-fader, post-EQ and post-
limiter signal sent to the auxiliary output.
D10) PFL Switch Button activates and deactivates Pre Fader Listening.
N.B.: When PFL is ON, the Master VU Meter will show the amplitude of the
signal entering the selected channel, bypassing both the EQ and Volume
settings. In the same way, headphones will only output the signals entering the
channels where PFL is turned on, pre-fader, post-EQ and post-compression.
D11) Channel Volume Fader regulates the channel volume.
D12) FX Send Knob regulates the amount of post-fader signal sent to the
effects processor.
D13) PAN Knob locates the channel in the stereo field.
D14) Channel Note displays an editable 8 character text.
D15) FX Master Volume Knob regulates the overall amount of effect to be
sent to the Master Output.
D16) FX to AUX Knob regulates the amount of effects on the AUX OUTPUT.
D17) Headphones Volume Knob regulates the Headphones Master Volume.
D18) Master Volume Fader regulates the Output Master Volume.
D19) VU Meter displays overall amplitude of Master Output.
N.B.: When one or more channels are in PFL mode, the Master VU Meter will
show the amplitude of the signal entering the selected channel, bypassing both
rev. C
F).
img. E).
KB1
pg. 35)
33
