Lamp Socket Assembly - ETC Source Four CE 405 Assembly Manual

Lamp Socket Assembly

13
11
Reference Part Number
1 7060A3055
2 7060A3007
3 7060A4007
4 7060A4008-02
5 7060A4011
6 7060A3011
7 7060A3012
8 HW748
9 7060B7013
10 HW534
11 7060A3025
12 HW746
13 HW5123
14 HW747
15 7060A3056
16 HW3103
17 HW5122
18 HW8209
19 7060B7014
20 7060B7013
21 HW749
22 HW349
23 7060A4037
24 HW2181
25 7060A3085
26 7060A7017
27 HW385
28 HW2125
Lamp Socket Assembly
1
3
4
8
12
21
22
4
26
Description
Housing, socket, casting, painted
Socket, light baffle casting, raw
Knob, X-Y, lamp set
Knob, Z, lamp set w/female insert
Bushing, cup
Hub, index, casting
Spring, lamp retainer
Spring, compression
Complete CE socket assembly
Nut, hex, 1/4-20, black zinc
Screw, 1/4-20 knurled head
Retaining ring, flat, Southco
Nut, hex, 9/16-18, black zinc
Washer, wave
Clamp, strain relief, painted
Screw, 8-32 x 5/8 PhFHMS, black zinc
Bolt, 1/4-20 x 1.75, full thread, black zinc
Clip Tinnerman
Source Four CE ground wire
Source Four CE cable assembly
Spring, ground
Washer, ext. #8
Handle, insulated rear, black
Screw, 6-32 x 3/4, Taptite
Source Four lamp retainer wire
Source Four retainer wire
Screw, 8-32 x 3/8, PhPHMS, SEMS
Screw, 6-32 x 3/8, PhFHTC, Typ 1, zinc
20
6
5
19
7
9
16
26
15
19
17
25
2
18
28
10
24
23
Figure 2
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
4
1
1
2
1
5
