Instruction Manual

2580
Hydraulic Installation Tool
December 21, 2017
HK961
Disassembly Procedure
Makers of Huck
, Marson
, Recoil
®
®
Brand Fasteners, Tools & Accessories
2
3-4
5
5-7
8
8
9
10
11
12-13
14-24
25
26
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2580 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Arconic 2580

  • Page 1: Table Of Contents

    Declaration of Conformity Instruction Manual 2580 Safety Instructions Hydraulic Installation Tool Description Specifications Principle of Operation Preparation for Use Operating Instructions Maintenance Disassembly Procedure Assembly Procedure 12-13 Components Drawings 14-24 Troubleshooting Kits and Accessories Makers of Huck , Marson , Recoil ®...
  • Page 2: Declaration Of Conformity

    2580 series Hydraulic Installation Tools (HK961)
  • Page 3: Safety Instructions

    2580 series Hydraulic Installation Tools (HK961) Safety Instructions assembly before installing the next fastener. GLOSSARY OF TERMS AND SYMBOLS: 15. Check clearance between trigger and work piece to - Product complies with requirements set forth by ensure there is no pinch point when tool is activated.
  • Page 4 2580 series Hydraulic Installation Tools (HK961) Safety Instructions (continued) IV. REPETITIVE MOTION HAZARDS: instructions and as required by occupational health and 1. When using assembly power tool, the operator can safety regulations. experience discomfort in the hands, arms, shoulders, 4. Operate and maintain tool as recommended in the neck or other parts of the body.
  • Page 5: Description

    2580 series Hydraulic Installation Tools (HK961) Description Huck’s 2580 series of Hydraulic Installation Tools—when The 2502 series of tools is designed to be powered by Hydraulic Unit (models 913, 918, 918- fitted with an appropriate nose assembly—installs a a Huck Powerig ®...
  • Page 6 2580 series Hydraulic Installation Tools (HK961) Specifications (continued) Figure 1...
  • Page 7 2580 series Hydraulic Installation Tools (HK961) Assembly Drawing Main Components Figure 2...
  • Page 8: Principle Of Operation

    2580 series Hydraulic Installation Tools (HK961) Principle of Operation When the hydraulic hoses and trigger control are released. Hydraulic pressure is directed to the RETURN connected to the Powerig Hydraulic Unit, an electric side of the piston, moving it forward. The tool and nose ®...
  • Page 9: Operating Instructions

    2580 series Hydraulic Installation Tools (HK961) Operating Instructions WARNINGS: - Wear approved eye and hearing The pressure is re-directed; the piston moves forward; protection. and the tool is pushed off the fastener and ready for the - Ensure adequate clearance for operator’s next installation cycle.
  • Page 10: Maintenance

    2580 series Hydraulic Installation Tools (HK961) Maintenance damage tool. See K & a ccessorIes CAUTIONS: - Follow the disassembly and assembly procedures in Consult the Material Safety Data Sheet this manual. If Huck-recommended procedures are not (MSDS) before servicing tool.
  • Page 11 If necessary to remove the hoses, slide back the plastic shrouds to access the hose fittings. 5. Model 2580: Loosen the strain relief grommet. Loosen the set screw and carefully pry out the switch with a small screw driver. Loosen the two wires at rear of the switch and remove it from the cord.
  • Page 12 GLYD ring on top of O-ring. Coat the GLYD ring with a suitable lubricant 14. Model 2580: Assemble the electrical cord to the to ensure it stays in place during piston installation. connector. Screw the strain relief grommet into the handle.
  • Page 13: Assembly Procedure

    2580 series Hydraulic Installation Tools (HK961) Assembly (continued) 15. Screw the coupling nipple onto the PULL Figure 4 pressure hose (from port P of tool). Screw the coupling body onto the RETURN pressure hose (from port R of tool). Installing the 16.
  • Page 14: Components Drawings

    2580 series Hydraulic Installation Tools (HK961) Sectional View 2580 Series Figure 5...
  • Page 15 2580 series Hydraulic Installation Tools (HK961) Control Cord & Hose Assembly 2580 Figure 5a...
  • Page 16 2580 series Hydraulic Installation Tools (HK961) Sectional View A2580 Figure 5b...
  • Page 17 2580 series Hydraulic Installation Tools (HK961) Control Cord & Hose Assembly Figure 5c ...to Cylinder/Handle (see Figure 5) Hose Assembly (See table below for part numbers.) 503431 110439 Reducing Female Bushing Connector 505839 Cable Ties (See table below for quantities.)
  • Page 18 2580 series Hydraulic Installation Tools (HK961) Assembly Drawing 2580 Figure 6...
  • Page 19 2580 series Hydraulic Installation Tools (HK961) Assembly Drawing A2580 Figure 7...
  • Page 20 2580 series Hydraulic Installation Tools (HK961) Assembly Drawing 2580-12 Figure 8...
  • Page 21 2580 series Hydraulic Installation Tools (HK961) Assembly Drawing 2580-25 Figure 9...
  • Page 22 2580 series Hydraulic Installation Tools (HK961) Assembly Drawing 2580-38 Figure 10...
  • Page 23 2580 series Hydraulic Installation Tools (HK961) Optional Hose Kit Figure 11...
  • Page 24 Sticker Locations The 2580 series tools are labeled with a Sticker (P/N 590424-7400) that contains safety and pressure settings information. This sticker must remain on the tool and be legible. If the sticker becomes damaged or worn, or if it has been removed from the tool, or when replacing Cylinder, this sticker must be ordered and placed in the location shown below.
  • Page 25: Troubleshooting

    2580 series Hydraulic Installation Tools (HK961) Troubleshooting Always check the simplest possible cause (such as a loose or disconnected trigger line) of a malfunction first. Then proceed logically, eliminating other possible causes until the cause is discovered. Where possible, substitute known good parts for suspected defective parts.
  • Page 26: Kits And Accessories

    8-A2580* Assembly Drawing A2580 H.I.T. Stroke Limiter Kit (P/N 125143) This kit reduces the stroke of any 2580 tool to 0.625 in. Air and Hydraulic Conversion Kit (P/N 125419) (15.87 mm). This kit converts the existing tool to the -2 version with a 2’...
  • Page 27 2580 series Hydraulic Installation Tools (HK961) Limited Warranties Limited Lifetime Warranty on BobTail® Tools: Tooling, Part(s) and Other Items not manufactured by Huck International, Inc. warrants to the original purchaser Huck: that its BobTail® installation tools manufactured after 12/1/2016 shall be free from defects in materials and HUCK makes no warranty with respect to the tooling, workmanship for its useful lifetime.
  • Page 28 Arconic Inc. (NYSE: ARNC) creates breakthrough products that Through the ingenuity of our people and cutting-edge advanced shape industries. Working in close partnership with our customers, manufacturing, we deliver these products at a quality and efficiency we solve complex engineering challenges to transform the way we that ensures customer success and shareholder value.
