EC Declaration of Conformity Safety Instructions 3-4, 8 Description Instruction Manual B4600 series Principle of Operation Battery-Powered Tool Specifications and Battery and Charger Safety Maintenance Preparation for Use Operating Instructions Components Drawing Attaching and Removing Nose Assemblies Kits and Accessories Follow the instructions contained in this document to ensure safe handling of the battery used with this tool. - Page 2 B4600 series Battery-Powered Tools (HK1189)
-
Page 3: Safety Instructions
B4600 series Battery-Powered Tools (HK1189) Safety Instructions 13. Do not abuse tool by dropping or using it as a hammer. GLOSSARY OF TERMS AND SYMBOLS: Never use hydraulic or air lines as a handle or to bend - Product complies with requirements set forth by or pry the tool. - Page 4 B4600 series Battery-Powered Tools (HK1189) Safety Instructions continued IV. REPETITIVE MOTION HAZARDS: VIII. NOISE HAZARDS: 1. When using the assembly power tool, the operator can 1. Exposure to high noise levels can cause permanent, experience discomfort in the hands, arms, shoulders, disabling hearing loss and other problems such neck or other parts of the body.
-
Page 5: Description
B4600 series Battery-Powered Tools (HK1189) Description Principle of Operation The B4600 tool is designed to install up to -08 MGL and The nose assembly is placed over the end of the fastener up to -06 MG and is compatible with standard “L” version until the tool’s anvil bottoms on the fastener. -
Page 6: Maintenance
B4600 series Battery-Powered Tools (HK1189) Battery and Battery Charger Safety • Take the charger out of its packaging before use. Insert WARNING: To protect against electric the accompanying battery correctly into the charger. shocks, injuries or fire hazards and RISK OF •... -
Page 7: Preparation For Use
B4600 series Battery-Powered Tools (HK1189) Preparation for Use WARNINGS: CAUTIONS: When operating Huck equipment always wear Do not abuse the tool by dropping it, using approved eye protection. Severe eye injury it as a hammer, or otherwise causing may occur if eyes are not protected. The tool unnecessary wear and tear. - Page 8 B4600 series Battery-Powered Tools (HK1189) B4600 omponents rawing 130944 Nose Adapter Assy O-ring Tool Spindle Extension Anvil Adapter 111795 Retaining Drive Unit 508736 Screws 508748 508738 Wiring Screw Harness 508749 Plate 508737 508750 Screws Bushing 508751 508745 Drive Unit Pintail Container...
-
Page 9: Components Drawing
B4600 series Battery-Powered Tools (HK1189) B4600s omponents rawing 130944-1 Nose Adapter Assy O-ring Tool Spindle Extension Anvil Adapter 111795 Retaining Drive Unit 508736 Screws 508748 508738 Wiring Screw Harness 508749 Plate 508737 508750 Screws Bushing 508751 508745 Drive Unit Pintail Container... -
Page 10: Attaching And Removing Nose Assemblies
B4600 series Battery-Powered Tools (HK1189) Attaching and Removing Nose Assemblies INSTALLING A NOSE ASSEMBLY Chuck Nose Spindle Jaws 1. Using a 1 inch wrench, NON-L SERIES Extension Spring remove Retaining Nut and (must be Follower removed Anvil Adapter. for use with... - Page 11 B4600 series Battery-Powered Tools (HK1189) Limited Warranties Limited Lifetime Warranty on BobTail® Tools: Tooling, Part(s) and Other Items not manufactured by Huck: Huck International, Inc. warrants to the original purchaser that its BobTail® installation tools manufactured after 12/1/2016 HUCK makes no warranty with respect to the tooling, part(s), or other items manufactured by third parties.
