Dual Regulator/Dual Voltage For Intel Mmx, Cyrix M2 (Or 6X86L), Amd K6; System Memory Configuration - SOLTEK SL-53A2 User's Manual & Technical Reference

Dual Regulator/Dual Voltage for Intel MMX, CYrix M2 (or 6x86L),
AMD K6
2.9V (Vcore)
2.8V (Vcore)
(for MMX, M2, 6x86L)

System Memory Configuration

This 82430VX motherboard supports 72-pin SIMMs of 4MB,
8MB, 16MB, or 32MB to form a memory size between 8MB
to 128MB. Follow the chart below to install the memory
modules.
Bank 0
SIMM 3 & 4
4MB x 2
8MB x 2
16MB x 2
32MB x 2
None
None
None
None
4MB x 2
4MB x 2
4MB x 2
4MB x 2
(for K6)
Figure 2Ð12Ð3 CPU Type Configuration
None
None
None
None
4MB x 2
8MB x 2
16MB x 2
32MB x 2
4MB x 2
8MB x 2
16MB x 2
32MB x 2
3.52V
(VI/O)
Bank 1
SIMM 1 & 2
MMX
Cyrix M2
AMD K6
CPU
Total Memory
8MB
16MB
32MB
64MB
8MB
16MB
32MB
64MB
16MB
24MB
40MB
72MB
Hardware Installation 17
