CPU 2.5X Clock Setting (Red Caps)

Intel Pentium – 150/166 MHz
Intel Pentium
JP11
JP12
1
Figure 2Ð7. INTEL Pentium CPU Type Configuration

CPU 3.0X Clock Setting (Red Caps)

Intel Pentium – 180/200 MHz
Intel Pentium
JP11
JP12
1
Figure 2Ð8. NTEL Pentium CPU Type Configuration
TAG
CPU
TAG
CPU
1
Intel Pentium – 150/60
PB
82438VX
SRAM
Intel Pentium – 166/66
PB
82438VX
SRAM
1
PB
82438VX
SRAM
PB
82438VX
SRAM
Hardware Installation 13
Intel Pentium – 180/60
Intel Pentium – 200/66
