6.1. Absolute Maximum Ratings

Absolute maximum ratings for power supply and voltage on digital and analog pins of module are listed in
the following table:
Table 30: Absolute Maximum Ratings
Parameter
VBAT_RF/VBAT_BB
USB_VBUS
Peak current of VBAT_BB
Peak current of VBAT_RF
Voltage at digital pins
Voltage at ADC0
Voltage at ADC1
UC20_Hardware_Design
Reliability
Min.
-0.3
-0.3
0
0
-0.3
0
0
Confidential / Released
UMTS/HSPA Module Series
UC20 Hardware Design
and
Radio
Max.
Unit
4.7
V
5.5
V
0.8
A
1.8
A
2.3
V
2.1
V
4.2
V
64 / 84
