3.4. Operating Modes

The table below briefly summarizes the various operating modes referred to in the following chapters.
Table 5: Overview of Operating Modes
Mode Details
UMTS Idle
UMTS
Talk/Data
Normal Operation
HSPA Idle
HSPA Data
Minimum AT+CFUN command can set the module entering into a minimum functionality mode
Functionality without removing the power supply. In this case, both RF function and USIM card will
Mode be invalid.
AT+CFUN command and W_DISABLE# pin can set the module entering into
Airplane Mode
airplane mode. In this case, RF function will be invalid.
In this mode, the current consumption of the module will be reduced to the minimal

Sleep Mode

level. During this mode, the module can still receive paging message, SMS and voice
call from the network normally.
In this mode, the power management unit shuts down the power supply. Only the
Power Down power supply for RTC remains. Software is not active. The serial interface is not
Mode accessible. Operating voltage (connected to VBAT_RF and VBAT_BB) remains
applied.

3.5. Power Saving

3.5.1. Sleep Mode
UC20 is able to reduce its current consumption to a minimum value during the sleep mode. The following
section describes UC20's power saving procedure.
UC20_Hardware_Design
Software is active. The module has registered to the UMTS
network and the module is ready to send and receive data.
UMTS connection is ongoing. In this mode, the power
consumption is decided by network setting (e.g. TPC pattern) and
data transfer rate.
Software is active. The module has registered to the HSPA
network and the module is ready to send and receive data.
HSPA data transfer is ongoing. In this mode, the power
consumption is decided by network setting (e.g. TPC pattern) and
data transfer rate.
