<CR> <LF> (0D
Error message:

8.2 Device Setup

8.2.1 Temperature Calculation

U=C Physical Unit for the temperature value
E=0.950 Emissivity setting
XG=1.000 Setting for transmission
For the calculation of the temperature value, it is possible to set an offset
(relative number to be added to the temperature value).
DO=-0.3 Offset adjustment -0.3 for the temperature signal

8.2.2 Post Processing

The following parameters can be set to determine the post-processing mode
P=5 maximum hold, hold time: 5 sec
F=12.5 minimum hold, hold time: 12.5 sec
G=10 averaging, average time (90%): 10 sec

8.3 Dynamic Data

To request the dynamic data, the following commands are available:
?T Target temperature
?I Detector ambient temperature
?XJ Temperature of Thermocouple cold end (only valid for TC)
?Q energy value of the target temperature
To check for resets (e.g. power shut down) use the command XI. Notice, after
a reset the unit is re- initialized.
?XI asks for the reset status
!XI0 no reset occurred
!XI1 a reset occurred, new initialization of the unit
XI=0 sets the reset status back to 0
CM
0A
h h
*Syntax Error "*" is the character for "Error".
Rev. B 06/2011
) is closing the answer.
Programming
30
