Mechanical Installation; Cable - RayTek RAYCMLTJM Operating Instructions Manual

Install and Operation

5.2 Mechanical Installation

All sensors come with a 1.0 m (3.3 ft) cable or 3.0 m (9.8 ft) and 2 mounting
nuts. You can mount the sensor in brackets or cutouts of your own design, or
you can use the mounting bracket accessories.
Figure 4: Sensor with fixed mounting bracket

5.3 Cable

The color code of the cable and 6 conductors are shown in the following table
8
Outer
Jacket
J brown
K yellow
0 to 5 V grey
** Die RS232's Ground must be connected to Power-
19
1 2
Power Power -**
+
orange black
Table 1: Sensor Wiring Color Code
Rev. B 06/2011
3 4 5
TxD/ TC+/
RxD
Alarm mV+
white
blue violet
yellow
yellow
:
6 7
TC-/ Shield
mV-
red
red
brown
CM
