P-Touch Template Settings Dialog Box - Brother QL-1110NWB User Manual

Change the Label Printer Settings

P-touch Template Settings Dialog Box

1 Default Command Mode
Specifies the P-touch Template mode as the default mode.
To change the mode, see the Management Tab on page 39.
2 Default Template Number
Specifies a default template number that the Label Printer sets when it is turned on. If you do not want to
transfer a template to the Label Printer, do not specify a template number.
3 Data Delimiter for P-touch Template
Displays a symbol used to indicate the boundaries between groups of data in a file (maximum of 20
characters).
4 Trigger for P-touch Template Printing
Specifies a trigger to begin printing from a number of options.
1
2
3
4
5
6
7
8
9
10
11
12
13
15
14
4
4
42
