UNPACK AND INSTALL YOUR RDX 8000
Desktop Installation
Place your RDX 8000 on a level, stable surface. Leave room behind the unit
for connecting cables and for airflow, and room in front for inserting
and removing cartridges.
Rackmount Installation
1. Determine where on the rack you will install the unit,
and mark the location on the vertical rails.
2. Using the included Torx screws and a T10 driver
fasten the rack ears to the unit as shown.
3. Align the unit with the marks on the vertical rails.
4. Using your fingers or a #3 Phillips screwdriver, tighten the
captive thumb screws to secure the unit to the rack.
Connect Power and Network Cables
Insert the included power cord in the AC power input, then connect it
to a power source that matches the requirements shown on the power
supply cover. The unit should now be in standby mode.
Insert the Ethernet cable in Port 1, then connect the cable to a gigabit
network switch or router.
,
(not included)
