Boyo Carrobot C2-Lite User Manual

Personal driving assistant which can project your phone's screen on an hud
Hide thumbs
Table of Contents

Advertisement

Quick Links

Carrobot C2-Lite User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Carrobot C2-Lite and is the answer not in the manual?

Questions and answers

Related Manuals for Boyo Carrobot C2-Lite

Summary of Contents for Boyo Carrobot C2-Lite

  • Page 1 Carrobot C2-Lite User Manual...

  • Page 3: Table Of Contents

    Table of Contents Introduction Disclaimer Carrobot components Installation Power supply instructions Button descriptions Screen cast instructions Troubleshooting Carrobot C2-Lite specs...

  • Page 5: Introduction

    Product introduction Carrobot C2-Lite is your personal driving assistant which can project your phone's screen on an HUD. It works both with Android phones and iPhones. It is designed to keep you safe and make your journey more efficient and...

  • Page 6: Disclaimer

    Disclaimer Looking away from the road can be dangerous. Watching HUD screens may increase your risk of distraction and accident. Vision Tech America, Inc. is not responsible for any damage, injury, or death due to the use of this product. Users assume all liability for all consequences, financial and otherwise while using this product.

  • Page 7: Carrobot Components

    Carrobot components Standard components: Carrobot, Carrobot power cord Carrobot OBD-II Connector Cigarette Lighter Adapter Cable Clamp OTG Cable Hexagon Spanner...

  • Page 8: Installation

    Installation Adhere Carrobot base to Install Carrobot on base. dashboard and adjust angle with hexagon spanner on Carrobot Saucer. Carrobot Saucer Connect Carrobot with Carrobot OBD-II Open re ective screen and connector/Cigarette lighter adapter. adjust to appropriate angle.

  • Page 9: Power Supply Instructions

    Power supply instructions When Carrobot is connected with Carrobot OBD-II connector/Cigarette lighter adapter, it will charge whenever you turn it on. We recommend that you charge your Carrobot with the provided Carrobot OBD-II connector/Cigarette lighter adapter. While connected to your car with the Carrobot OBD-II connector/Cigarette lighter adapter, the unit can be turned on or o automatically when you operate your vehicle.

  • Page 10: Button Descriptions

    Button descriptions There are three buttons on Carrobot. You can switch between Android screen cast or iPhone screen cast very easily with a short press on the “Mode switch button”. Mode switch button Volume up button Volume down button...

  • Page 11: Screen Cast Instructions

    Screen cast instructions Android You can choose either wired or wireless connections to mirror your phone screen to the HUD. Please verify that the HUD is in the correct state to pair with the device before connecting. Wired connection method...
  • Page 12 Switch Carrobot to Android screen cast mode. Note: The interface is inactive when mobile phone is disconnected.
  • Page 13 Connect OTG Cable to the HUD. OTG Cable...
  • Page 14 Use the charger cable to connect both OTG cable and the phone. OTG Cable Charger Cable...
  • Page 15 Open the phone settings and turn on the USB tethering mode (which is generally located in the system settings - Tethering&portable hotspot).
  • Page 16 Please choose “allow the use of this computer debugging” in the pop-up window, then click OK and wait until the Carrobot connects, you can cast phone screen now. Note:All sounds will play from phone.
  • Page 17 Wireless connection method Switch Carrobot to Android screen cast mode. Note: The interface is inactive when mobile phone is disconnected.
  • Page 18 Please choose “Multi-cast” in your phone setting screen. Note: It will display in di erent names for di erent brand phone, such as “Cast”, “Multi-cast”.
  • Page 19 Connect your phone with “C2-Lite-xxxxxx” device, when the Carrobot receives the signal, you can then begin the screen cast. Note: If the projection image is vertical screen display screen, please try to cross screen phone rotation state and check the settings if needed.
  • Page 20 iPhone You can choose either wired or wireless connections to mirror your phone screen to the HUD. Please verify that the HUD is in the correct state to pair with the device before connecting. Wired connection method...
  • Page 21 Switch Carrobot to iOS screen cast mode. Note: The interface is inactive when mobile phone is disconnected.
  • Page 22 Connect OTG Cable to the HUD. OTG Cable...
  • Page 23 Use the Charger Cable to connect both OTG Cable and the phone. OTG Cable Charger Cable...
  • Page 24 Choose “Trust” in the pop-up window.
  • Page 25 Choose the system settings, then turn on your phone’s hotspot, wait for the top tip “personal hot spots: 1 connection”.
  • Page 26 Turn on “AirPlay mirroring”, select the “C2-Lite-xxxxxx” device. Once the Carrobot receives the signal, you can then begin the screen cast. Note: If the projection image is vertical screen display screen, please try to cross screen phone rotation state and check the settings if needed.
  • Page 27 Wireless connection method Switch Carrobot to iOS screen cast mode. Note: The interface is inactive when mobile phone is disconnected.
  • Page 28 Turn on “Wi-Fi”,connect your phone with “C2-Lite-xxxxxx” device.
  • Page 29 Turn on “AirPlay mirroring”, select the “C2-Lite-xxxxxx” device. Once the Carrobot receives the signal, you can then begin the screen cast. Note: If the projection image is vertical screen display screen, please try to cross screen phone rotation state and check the settings if needed.

  • Page 30: Troubleshooting

    Troubleshooting What is the di erence between Carrobot Lite and Carrobot Pro? Carrobot Lite must be operated with the Phone APP on your mobile device while Carrobot Pro can operate as a standalone device. Can I insert a SIM card into Carrobot Lite for Internet? No, you can’t.
  • Page 31 Will GPS navigation be interrupted when the phone is ringing? Yes, it will, as the GPS navigation application is installed on the phone. Can I cast any phone app to Carrobot? Yes. (Note: For your safety, restrict screen casting to GPS navigation app while driving.)
  • Page 32 Is that OK if I cast phone screen to Carrobot with both wired and wireless method? No, it may cause some unpredictable problems. We recommend screen casting in 'Wired Mode' for best results. What if my car doesn’t support OBD-II connector to the HUD? You can use the included cigarette lighter adapter.

  • Page 33: Carrobot C2-Lite Specs

    Carrobot C2-Lite specs Model Carrobot C2-Lite OBD-II connector & Accessories Cigarette lighter adapter Single-core ARM-A9 Pair with Mobile App Operating Mode 160.08mm about 8ft. Projected Distance 162.00mm 18 inches Virtual image size Automobile standard TFT LCD Display Multi-layer nanometer optical coated acrylic Screen Type 8o2.11 b/g/n,support WIFI connecting and hotspot...
  • Page 36 Vision Tech America, Inc. For U.S. 888-941-3060 International 714-446-0543 www.visiontechamerica.com...
