BOYO® WiFi High Resolution Rear View camera System
1.Parts list
A. 5" Wireless Monitor x 1
E. Monitor & Camera Power Cable x 2
2. Testing
3. Preparations
G) Turn the key to the on position, the power of the vehicle is on.
4.Camera Installation
CD Remove the license plate
user·s manual
B. Wireless Bar•Type Camera x 1
F. Cigarette Lighter Cord w/ USB Port x 1
Testing,
@
Shift to the reverse gear, the reverse light is on.
@
Run the power cable of the camera
in the vehicle.
C. Suction Cup Mount x 1
G. Camera Mounting Hardware x 2
When the vehicle is in reverse gear, the system will work
automatically. The wireless camera will send the video
signal to the wireless monitor. When the vehicle is shifted
out of reverse gear, the system will shut down.
@
Install the camera onto the license plate,
@
use the supplied screws, washers and nuts.
VTC525R
D. Suction Cup Mount Bracket x 1
H. User's Manual x 1
